SME 100 • Setup Guide (Continued)
Connect audio input devices to the audio captive screw connectors (inputs 1 through 3;
z
unbalanced 3.5 mm, 5-pole captive screw connectors. See the image below to wire the connectors.
Tip
Ring
Sleeves
Tip
Ring
Balanced Stereo Input
Step 3 — Connect Buffered Loop Output Devices (Optional)
If necessary, connect output devices to the following buffered loop connectors. Buffered loop connectors output the input video
that is connected to a similar input connector (for example, BNC buffered loop connectors output BNC video).
Connect a video output device to the component, S-video, composite BNC buffered loop connectors (
z
Connect a video output device to the 15-pin HD buffered loop connector (
z
Connect a high resolution digital output device to the DVI buffered loop connector (
z
Connect audio output devices to the buffered loop audio captive screw connectors (
z
unbalanced 3.5 mm, 5-pole captive screw connectors. See the image below to wire the connectors.
ATTENTION: For unbalanced audio, connect the sleeves to the ground contact. DO NOT connect the
sleeves to the negative (–) contacts.
Tip
Ring
Sleeves
Tip
Ring
Balanced Audio Output
Step 4 — Connect RS-232 Control Device (Optional)
If necessary, connect a host computer or control system to the RS-232 connector (
Set (SIS™) commands to the SME 100 for device configuration and control. The default protocol for this port is:
9600 baud rate, no parity bit, 8 data bits, 1 stop bit, and no flow control (handshaking).
Step 5 — Connect the SME 100 to the Network
Connect one end of an RJ-45 cable to the Ethernet connector (
a router or switch to connect the SME 100 to a network.
The LEDs on the Ethernet connector indicate the status of the network connection. The green LED lights when connected to a
network. The amber LED flickers as the SME 100 actively communicates with a network.
Step 6 — Connect Control PC and Viewing Devices to the SME 100 Network
Connect one end of an RJ-45 cable to a control PC or viewing device. Connect the other end of the RJ-45 cable to a router or
switch to connect the control PC or viewing device to the network.
Step 7 — Power On the SME 100 and All Devices
Connect a standard IEC power cord into the AC power connector (
50 Hz or 60 Hz power source. Connect the power cords of the input and output devices and turn them on.

Powering Up

When applying power to the SME 100, the unit undergoes a self-testing sequence (see the image below). After the testing
sequence is complete (and when the device is not being configured), the default display cycle is shown on the LCD display.
The default display cycle shows the model name/firmware version, active input/output signal format, active input/horizontal and
vertical scan rate, stream mode/output resolution,
and stream method/AV bit rate in kilobits per second (Kbps).
