VDSL2 PoE Ethernet Extender Kit, PD
Extend Ethernet with 100-/60-Mbps downstream/
upstream connections over copper.
Kit includes two extenders—one with standard power and one that's a PoE
powered device (PD).
Bridges 10BASE-T/100BASE-TX Ethernet interface.
Supports DSL connection up to 4000 feet (1219 m).
Select from Fast and Interleaved modes.
Provides low latency for video/voice/data applications.
IEEE 802.3af PoE compliant.
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) •
Customer
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 •
Support
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 •
Information
Web site: www.blackbox.com • E-mail: info@blackbox.com
BLACK BOX
December 2009
LBPD01A-KIT
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box LBPD01A-KIT
Summary of Contents for Black Box LBPD01A-KIT
-
Page 1: Black Box
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) • Customer FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 • Support Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 • Information Web site: www.blackbox.com • E-mail: info@blackbox.com... - Page 2 VDSL2 PoE Ethernet Extender Kit, PD Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
- Page 3 FCC and IC RFI Statements Federal Communications Commission and Industry Canada Radio Frequency Interference Statements This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial environment.
- Page 4 VDSL2 PoE Ethernet Extender Kit, PD Normas Oficiales Mexicanas (NOM) Electrical Safety Statement INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3.
- Page 5 CE Statement European Community (CE) Electromagnetic Compatibility Directive This equipment has been tested and found to comply with the protection requirements of European Emission Standard EN55022/EN61000-3 and the Generic European Immunity Standard EN55024. EMC: EN55022(2003)/CISPR-2(2002): Class A IEC61000-4-2 (2001): 4 KV CD, 8 KV AD IEC61000-4-3(2002): 3 V/m IEC61000-4-4(2001): 1 KV (power line), 0.5 KV (signal line) Page 5...
-
Page 6: Table Of Contents
VDSL2 PoE Ethernet Extender Kit, PD 1. Specifications ......................................7 2. Overview ......................................... 8 2.1 Introduction ...................................... 8 2.2 Features ......................................8 2.3 Application ....................................... 8 2.4 What’s Included ....................................9 2.5 LED Descriptions ....................................9 2.6 Front and Back Panels ..................................10 3. -
Page 7: Specifications
Chapter 1: Specifications 1. Specifications Data Rate (Maximum): 100/60 Mbps Transmission Distance (Maximum): 4000 ft. (1219 m) Flow Control: Half-/full-duplex MDI-X: Automatic Standards: ITU-T G.993.1/2, SG15Q4 DMT compliant, trellis code with 1024 DMT bins, EMI emissions compliant, FCC Class A, CE, IEEE 802.3/IEEE 802.3u Ethernet, 10BASE-/100BASE-TX, IEEE 802.3af PoE PoE Power Reception Supports: Endpoint: Via twisted-pair: Pins 1, 2, 3, 6;... -
Page 8: Overview
PoE powered device (PD). The PD extender draws its power from a Power over Ethernet (PoE) switch, so you can easily integrate it into a PoE infrastructure without using another power outlet. The LBPD01A-KIT is ideal for high- bandwidth applications such as LAN-to-LAN, video streaming, FTTB, and MDU/MTU over single twisted-pair telephone lines. -
Page 9: What's Included
Chapter 2: Overview 2.4 What’s Included Your package should include the following items. If anything is missing or damaged, please contact Black Box Technical Support at 724-746-5500. • (1) VDSL2 PoE Ethernet Extender (PD) • (1) VDSL2 PoE Ethernet Extender (Standard) •... -
Page 10: Front And Back Panels
VDSL2 PoE Ethernet Extender Kit, PD 2.6 Front and Back Panels Figures 2-2 through 2-5 show the extenders’ front and rear panels. DIP Switches LED Indicators Figure 2-2. Front panel, VDSL2 PoE Ethernet Extender (PD), PD unit. RJ-45 Connector RJ-11 Connector Figure 2-3. -
Page 11: Installation
Chapter 3: Installation 3. Installation Because the VDSL2 PoE Ethernet Extenders are preconfigured for basic applications, you can install them quickly. Follow these steps: 1. Connect the line interface between the units with RJ-11 cable. 2. Connect the Standard Extender to a twisted-pair Ethernet connection. Connect the PD Extender to a PoE PSE switch or other PSE device using copper twisted-pair cable. -
Page 12: Dip Switches
VDSL2 PoE Ethernet Extender Kit, PD 4. DIP Switches Table 4-1 describes the DIP Switches. Select the switches for optimal configuration. Table 4-1. DIP switches and their functions. DIP Switches SW-1 SW-2 SW-3 SW-4 Definition Master/Slave Impulse Noise Data Rate Protection Mode Master Interleaved... - Page 13 About Black Box Black Box Network Services is your source for more than 118,000 networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 20 seconds or less.
