Magnum 261805 Operation Manual

Project painter 7 airless sprayers
Hide thumbs Also See for 261805:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Repair Parts Manual
Operation
Project Painter 7 Airless Sprayers
- For portable spray applications of architectural paints and coatings -
Model: 261805
Maximum Working Pressure: 3000 psi (21 MPa, 207 bar)
Dispense Rate: 0.31 gpm (1.17 lpm)
Includes:
Gun: SG10
Hose: 1/4 inch x 35-ft. (6.4 mm x 11 m)
9 inch Pressure Roller Attachment
IMPORTANT SAFETY INSTRUCTIONS.
Read all warnings and instructions in this
manual. Save these instructions.
Use water-based or mineral spirit-type materials only.
Do not use materials having flash points lower than
70°F (21°C). For more information about your mate-
rial request MSDS from distributor or retailer.

Specifications

This equipment is not intended for use with flammable or combustible
materials used in places such as cabinet shops or other "factory" or
fixed locations. If you intend to use this equipment in this type of appli-
cation, you must comply with NFPA33 and OSHA requirements for the
use of flammable and combustible materials.
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2007, Graco Inc. is registered to I.S. EN ISO 9001
The manual provided with this
sprayer contains
English, Español and Français.
Visit our website;
http://M
.Graco.com
AGNUM
312082B
ti9194a
ti9338a
ti9208a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 261805 and is the answer not in the manual?

Questions and answers

Related Manuals for Magnum 261805

Summary of Contents for Magnum 261805

  • Page 1: Specifications

    .Graco.com AGNUM Project Painter 7 Airless Sprayers 312082B - For portable spray applications of architectural paints and coatings - Model: 261805 Maximum Working Pressure: 3000 psi (21 MPa, 207 bar) Dispense Rate: 0.31 gpm (1.17 lpm) Includes: Gun: SG10 Hose: 1/4 inch x 35-ft. (6.4 mm x 11 m) 9 inch Pressure Roller Attachment IMPORTANT SAFETY INSTRUCTIONS.
  • Page 2 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. Refer back to these warnings. Additional, product specific warnings may be found throughout the body of this manual where applicable.
  • Page 3 Warnings WARNING EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not exceed the maximum working pressure or temperature rating of the lowest rated system component. Read Technical Data in all equipment manuals. • Use fluids and solvents that are compatible with equipment wetted parts. Read Technical Data in all equipment manuals.

  • Page 4: Installation

    Installation Installation Smaller gauge or longer extension cords may reduce sprayer performance. Grounding and Electric Fluid supply container: follow local code. Requirements Solvent pails used when flushing: follow local code. Use only conductive metal pails, placed on a grounded surface such as concrete. Do not place the pail on a nonconductive surface, such as paper or cardboard, which interrupts grounding continuity.

  • Page 5: Component Identification

    Component Identification Component Identification Project Painter 7 ™ • STORAGE: for long term and overnight shutdown and storage. AllControl • OFF: turns motor off for short term shutdown and relieves system pressure. • PRIME/CLEAN PUMP: turns on motor and directs fluid to prime tube.
  • Page 6 Component Identification ti9724a ti9312a ti9307a ti9310a ti9309a ti9338a ti9168a ti9257a ti9208a 312082B...

  • Page 7: Getting Started

    Getting Started Getting Started Trigger Lock Always engage the trigger lock when you stop spraying to prevent the gun from being triggered accidentally by hand or if dropped or bumped. 1. Set AllControl to OFF. Unplug sprayer. ti9168a ti9207a ti8923a ti8922a 2.
  • Page 8 Getting Started Setup Priming and Flushing Storage Fluid 1. Set AllControl to OFF. Engage Before you use your sprayer for the first time or begin a gun trigger lock. new spraying project, you need to prime the sprayer and flush the storage fluid out of the sprayer. Oil- or Water-based Materials ti9168a •...
  • Page 9 Getting Started b. unlock gun trigger lock. 3. Place prime tube in waste pail. c. pull and hold gun trigger. ti8922a d. set AllControl to ti9652a PRIME/CLEAN GUN & 4. Submerge Suction tube in HOSE. water or flushing solvent. ti9171a 12.

  • Page 10: Spraying Techniques

    Getting Started Install Tip and Guard Spraying Techniques Preventing Excessive Tip Wear • Spray should be atomized (evenly distributed, no gaps at edges). Start at low pressure setting, increase pressure a little at a time until you see a 1. Engage trigger lock. good spray pattern, without tails.

  • Page 11: Unclogging Spray Tip

    Getting Started Unclogging Spray Tip 3. Aim gun at piece of scrap or cardboard. 4. Unlock trigger lock. Pull trigger to clear clog. To avoid fluid splashback: • Never pull gun trigger when arrow-shaped handle is between SPRAY and UNCLOG positions. to8922a •...

  • Page 12: Reversible Tip Selection Chart

    Getting Started Choosing the Correct Tip for the Understanding Tip Number The last three digits of tip number (i.e.: 221413) contain information about hole size and fan width on surface Consider coating and surface to be sprayed. Make sure when gun is held 12 in. (30.5 cm) from surface being you use best tip hole size for that coating and best fan sprayed.

  • Page 13: Getting Started With Basic Techniques

    Getting Started With Basic Techniques Getting Started With Basic Techniques Use the Practice Spray Board to practice these basic spraying techniques before you begin spraying the surface. Aiming Gun • Hold gun 12 in. (30 cm) from surface and aim straight at surface.
  • Page 14 Rolling Rolling Setup Tighten nut with wrench while keeping gun and roller aligned. • Follow Priming instructions, beginning on page 8, 6. Unlock gun trigger safety. Trigger prior to assembling roller. gun. Roll surface until paint is fully • After priming, only paint should come out of spray dispersed on roller.
  • Page 15 Rolling Rolling Techniques Ceilings, Walls and Woodwork 1. Rolling vertically, roll out 1. Ceilings: Using a paint the letter “M”. brush, apply a starting row of tiFig5 paint approximately the width of your paint brush where the walls and ceiling meet. tiFig2 2.

  • Page 16: Shutdown And Cleaning

    Shutdown and Cleaning Shutdown and Cleaning Pail Flushing 5. Place waste and paint pail side by side. • For short term shutdown periods (overnight to two days) refer to Short Term Storage, page 21. • For flushing after spraying water-based coatings, use water.
  • Page 17 Shutdown and Cleaning 14. Stop triggering gun. Engage trigger lock. Step 12 is for returning paint in hose back to paint 15. Turn AllControl to OFF. pail. One 50-ft hose holds approximately 1-quart (1-liter) of paint. 12. To preserve paint in hose: a.

  • Page 18: Cleaning Roller

    Shutdown and Cleaning Cleaning Roller b. Unlock trigger lock. ti8922a 1. Relieve Pressure, page 7. c. Turn AllControl to the PRIME/CLEAN GUN & 2. Remove roller cover (a) and core (b) from roller HOSE. frame (c) as follows: a. Using your thumb, press clip (d) to release roller and core into waste pail.

  • Page 19: Power Flush

    Shutdown and Cleaning Power Flush 9. Unscrew inlet screen from Power flushing is a faster method of flushing. It can only Suction tube. Place inlet screen be used after spraying water-based coatings. in waste pail. 1. Relieve pressure, page 7. 2.
  • Page 20 Shutdown and Cleaning 19. Turn off garden hose. Close Power Flush attachment. Step 15 is for returning paint in hose back to paint pail. One 50-ft (15-m) hose holds approximately 1-quart (1-liter) of paint. ti9413a 15. To preserve paint in hose: a.

  • Page 21: Short-Term Storage

    Storage Storage Short Term Storage Long Term Storage (more than 2 days) (up to 2 days) • Always circulate Pump Armor storage fluid through system after cleaning. Water left in 1. Turn AllControl to OFF. Pause 2-3 seconds to allow sprayer will corrode and ruin pump.

  • Page 22: Stowing Sprayer

    Storage Stowing Sprayer Storage Options CAUTION • Before storing sprayer make sure all water is • For compact storage, drained out of sprayer and hoses. open Quick Release • Do not allow water to freeze in sprayer or hose. Latches (a) and fold •...

  • Page 23: Troubleshooting

    Troubleshooting Troubleshooting Check everything in this Troubleshooting Table before you bring the sprayer to a Graco/Magnum authorized service center. Problem Cause Solution AllControl is on and sprayer is plugged in, Pressure is too low. Turn AllControl clockwise to increase but motor does not run, and pump does pressure setting.
  • Page 24 Troubleshooting Problem Cause Solution Spray gun stopped spraying. Spray tip is clogged. Unclog spray tip, page 11. Pump cycles but does not build up Pump is not primed. Prime pump. pressure. Inlet screen is clogged or Suction tube is Clean debris off inlet screen and make not immersed in fluid.
  • Page 25 Troubleshooting Problem Cause Solution Motor is hot and runs intermittently. Vent holes in enclosure are plugged or Keep vent holes clear of obstructions and This is NOT a thermal overload condition. sprayer is covered. overspray and keep sprayer open to air. Motor automatically shuts off due to Extension cord is too long or not a heavy Replace extension cord.

  • Page 26: Maintenance And Service

    Maintenance and Service Maintenance and Service Paint Hoses CAUTION Protect the internal drive parts of this sprayer Check hose for damage every time you spray. Do not from water. Openings in shroud allow cooling of attempt to repair hose if hose jacket or fittings are dam- mechanical parts and electronics inside.

  • Page 27: Technical Data

    Technical Data Technical Data Working pressure range 0-3000 psi (0-21 MPa, 0 -207 bar) Electric motor 6.5 AMP (open frame, universal) Operating horsepower Maximum delivery (with tip) 0.31 gpm (1.17 lpm) Paint hose 1/4 in. x 35 ft (6.4 mm x 11 m) Maximum tip hole size 0.017 in.

  • Page 28: Graco Standard Warranty

    Graco Standard Warranty Graco Standard Warranty Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
