14. SPECIFICATIONS

Speakers power handling
20
Max power
Impedance
Frequency range
SPL 1W / 1mt
Maximum SPL
Horizontal
Vertical
Type
Frequency High pass @100 Hz, 24 dB/oct suggested minimum
Full range
Connectors
Wiring
Vertical pattern
Impedance
Dimensions
Weight
1. Maximum RMS applicable power for a musical signal, the
reference signal is the one proposed by EIAJ standard.
2. Measured @4 mt then scaled @1 mt
New materials and design are introduced into existing products
without previous notice. Present systems may differ in some
respects from those presented in this brochure.
KP52
Acoustics
360 W
600 W
8Ω or 32Ω (selectable)
100 Hz - 20 KHz.
96 dB
118 dB continuous - 124 dB peak
Coverage
90°
10°- 45° (selectable)
Crossover
External Crossover required
Transducers
6 x 3.15" Neodymium magnet with 1" voice coil
Power Audio Input
2 x 4-pin Speakon
1+ 1-
(signal IN & LINK);
Selection Switch
Spoot - Flood
8Ω - 32Ω
Physical
8.8 x 50 x 11.8 cm (3.56" x 19.7" x 4,65")
6 kg (13.23 lbs)
(AES)
1
2
2+ 2-
(through)
