- Page 1 G1 S TRENGTH 3-ST ACK MUL TI-GYM...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION It is the sole responsibility of the purchaser of MATRIX Fitness Systems products to instruct all individuals, whether they are the end user or supervising personnel on proper usage of the equipment. It is recommended that all users of MATRIX Fitness Systems exercise equipment be informed of the following information prior to its use. - Page 3 WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID INJURY! 1. Never allow children on freeweight equipment. Teenagers must be supervised at all times while using this equipment. 2. All warnings and instructions should be read and proper instruction obtained prior to use. 3.
-
Page 4: Tools Required For Assembly
UNPACKING G1MG30 3-Stack Multi-Gym Thank you for purchasing a MATRIX Fitness product. This machine is an EN957-1 and EN957-2 complaint Class S product. Your MATRIX G1MG30 3-Stack Multi-Gym is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact packaging of the machine. Prior to assembly, confirm all the components by matching them with the exploded diagrams. - Page 5 Step 1 Frame Detail Item Description Screw (M10 X 80L) Screw (M10 X 70L) Z02 Z03 Z04 Flat Washer (M10) Nylon Nut (M10) Screw (M10 X 100L) Z03 Z04 Z04 Z03...
- Page 6 Step 2 Item Description Screw (M10 X 80L) Screw (M10 X 70L) Flat Washer (M10) Nylon Nut (M10) Screw (M10 X 105L) Screw (M10 X 95L)
- Page 7 Step 3 Item Description Guide Rod( 19x1800L) Guide Rod Selector Pin Rubber Guide Rod Bushing Stop Ring Rubber Stack Cushions Lower Rubber Stack Screw (M8 X 45L) Screw (M8 X 65L) Flat Washer (M8) Nylon Nut (M8)
- Page 8 Step 4 Item Description Flange Bushing ( 25.3 X 9.2L) Shaft ( 20 X 130L) Screw (M10 X 80L) Screw (M10 X 70L) Flat Washer (M10) Nylon Nut (M10) Screw (M10 X 65L) Screw (M10 X 30L) Screw (M10 X 160L) Screw (M10 X 100L) Shaft ( 20x87L) Screw (M10 X 75L)
- Page 9 Step 5 Description Item Nylon Nut (M12) Flat Washer (M10) Nylon Nut (M10) Screw (M12 X 152L) Screw (M10 X 140L) Screw (M10 X 115L) Screw (M10 X1 75L) Flange Bushing (M15x20.5L) Flat Washer (M12) H44 Z71...
- Page 10 Step 6 Item Description Long Lat Bar Cable( 4.8x4130L) Cable( 4.8x5205L) Cable( 44.8x4300L) Cable( 44.8x3475L) Pulley ( 90) Karabiner Short Bar Pulley ( 115) Screw (M10x70L) Flat Washer (M10) Nylon Nut (M10) Flange Bushing ( 16x11L) Screw (M10 X 95L) Screw (M10 X45L) Flange Bushing ( 15x21.5L) Flange Bushing ( 15x19.5L)
- Page 11 Step 7 Description Item Shaft ( 20 X 192L) Flange Bushing ( 25.3x33L) Shaft( 20x79.5L) Right End Cover Left End Cover C Clip External End Cover Teflon Washer Flat Washer (M10) Screw (M10 X 25L) Screw (M10 X30L) Flat Washer (M8) Small Disc (hole size) Large Disc (hole size) End Cap...
- Page 12 Step 8 Item Description Q01 Front Shield Front Shield Front Shield Z20 Screw (M8 X 20L)
- Page 13 Adjust the pressing arm into the lower positions for the Bench Press exercise. 2. Adjust the pressing arm in the upper positions for the Shoulder Press exercise. Back pad adjusts to correspond with the angle of the pressing arm. 4. Seat pad adjusts to provide secure and comfortable positioning. MULTI-POSITION PRESS Pull-knob located behind the back pad adjusts the machine between exercises.
- Page 14 MATRIX F ITNESS | 1600 L AND MARK D RIVE COT TAGE GROVE WI 53527 USA To l l Fre e m a t r i x f i t n e ss . co m Fa x 866. 693.4863 608.
