Module features

Transmitter module
(AV104 model pictured)
Video
input
from
Audio
source
input
PC
from
Local
source
video
PC
output
Local
audio
output
Variation for
AV100 transmitter
Single link out
connector
Power supply connection
Link output to receiver 1
Link outputs to
receivers 2, 3 & 4
(AV104 only)
Variation for
AV200 transmitter
Serial port
connection
to source PC
Single link out
(male 9-way )
connector
Receiver module
(AV101 model pictured)
Indicators
Indicators
Link output to
cascaded receiver
(AV101 only)
Link input from
transmitter (or
cascade input)
Variation for
AV100 receiver
Single link in
connector
(also no skew
compensation adjusters)
Audio output to speakers
Video output to display
Audio output to speakers
Sharpness control
Brightness control
Power
supply
connection
Variation for
AV200 receiver
Serial port
connection
to device
Single link in
(female
connector
9-way )
Video output
to display
Skew adjusters
(not AV100)
6
