ADDER ADDERLINK AV200 Series Specification

ADDERLINK AV200 Series
The professional choice for audio, video and RS232 distribution
PRODUCT IN BRIEF
Distribute crisp, clear and bright VGA, CD
quality audio and transparent RS232 from a
single PC to 64 screens up to 300m/1000ft
from a play out device. For Digital Signage
and Media Streaming applications.
The AdderLink AV200 Series is a range of
audiovisual extenders delivering high video
resolutions, superb quality audio and RS232
up to 300m using standard CATx cable
(x=5,5e,6,7) The innovative design allows
for flexible audiovisual distribution, manage-
ment, control and interaction with the
display devices which can be expanded
to grow in line with project developments.
Consisting of 5 interchangeable units, the
AdderLink AV200 Series makes the design
of digital signage and narrow casting applica-
tions cost effective, flexible and easy to plan.
audio, video and RS232 distribution
FEATURES
Video performance
Industry leading resolutions of 1600x1200 are
achievableat 200m (650ft) and 1280x1024 at
300m 1000ft).
Display Management via RS232
Included with AV200 transmitters, the Display
Management Software gives users control
and interaction with display devices over
the integrated RS232 ports. This allows for
bi-directional and automated communication
with individual screens, groups of screens or all
screens at the same time.
Video compensation and brightness control
The AdderLink AV units can apply a high level of
signal compensation and brightness correction
that ensures the image is crisp, clear and bright
over long distances.
Audio
Digital audio transmission delivers high fidelity;
click-less audio for speakers and microphones.
Integrated DeSkew
The AdderLink AV201R has integrated skew
correction with a 300MHz bandwidth, meaning
that it is more than powerful enough to
counteract the negative effects of the skew.
Rack options
Both transmitter and receiver units can be
used standalone or can be mounted into a 3U
chassis, (up to 16 200T, 200R and 201T units or
8 204T and 208T units).
Digital Signage
Professional AV
High density, small form factor
AdderLink ALAV200T (transmitter) and
ALAV200R (receiver)
• Sold individually or as a pair (AdderLink
AV 200R)
• Local port on transmitter to connect
local screen, speakers and serial or for
cascading
• AdderLink AV 200R duplicates input from
transmitter allowing for 2 video and 2
audio outputs
• Control or manage either screen via
RS232
AdderLink ALAV204T and ALAV208T
(transmitters)
• Extends a single high-resolution video,
high fidelity audio and RS232 signals to
4 (AV204T) or 8 (AV208T) different
receivers
• Local port to connect local screen,
speakers and serial or to cascade to
other AdderLink AV 204T or AV 208T
transmitter units
AdderLink ALAV201R (receiver) unit
• Duplicates input from transmitter
allowing for 2 video, 2 audio outputs
• Control or manage either screen via
RS232
