Fi xe d D o m e C am e ra
KCM-3211
PHOTO INDICATION
1
2
3
1
Reset Button
2
Power Button
3
Ethernet Port
4
Digital Input / Output
ACCESSORY OPTIONS
Dome Cover
PDCX-1101
Power Adapter
PPBX-0002
w w w . a c t i . c o m
4
5
6
7
5
DC 12V Power Input
6
MicroSD / Micro SDHC Card Slot
7
Audio Input / Output
4-inch, smoke, vandal proof
Universal Power Adapter,
100~240V,
4 different connectors included
* Latest product information: www.acti.com/product/
* Accessory information: www.acti.com/accessory/
3.6x Zoom H.264 4-Megapixel IP D/N
PoE Indoor Dome with P-Iris
• 1/3.2" Progressive Scan CMOS
• Day and night function with mechanical IR cut filter
• Minimum illumination 0.05 lux at F1.4
• 3.6 x optical zoom
• Built-in f3.3-12 mm / F1.4 Megapixel P-Iris zoom lens
• 8 fps at 2032 x 1920 resolution (1373 TV lines)
• Selectable H.264, MPEG-4 SP, MJPEG compressions
• with dual streaming
• Up to 4 cropped regions as independent channels
• Two-way audio
• Digital input and digital output
• MicroSD/ MicroSDHC card slot for local storage
• Video Motion Detection
• Powered by PoE Class 3 / DC 12V
DIMENSION DIAGRAM
Ø146.00
Popular Mounting Solutions
Surface
Accessories not required
Wall
PMAX-0308
Pendant
PMAX-0101
PMAX-0103
Corner
PMAX-0101
PMAX-0303
PMAX-0402
Pole
PMAX-0101
PMAX-0303
PMAX-0502
Flush
PMAX-1008
* For more mounting solutions, please refer to Mounting Accessory section of Buyer's
Guide or Project Planner on www.acti.com
[5.7]
Unit: mm [inch]
+
+
+
+
+
120220
