- Page 1 Indoor PTZ Mounting on a Straight Wall Using the L-Bracket Installation Guide For Models: I91, I92, KCM-8111 2013/12/09...
- Page 2 Installation Guide Table of Contents Installation Procedures ............. 3 Step 1: Install the L-Type Wall Mount ............3 Step 2: Install the Camera ................. 5 Step 3: Access the Camera Live View ............6 Safety Information .............. 7 www.acti.com...
-
Page 3: Installation Procedures
To connect a power adapter or a digital input/output device, the bundled terminal block must be attached to the cables. For more information on connecting the terminal blocks, refer to the camera model Hardware Manual downloadable from the website (www.acti.com). www.acti.com... - Page 4 Then route the cable through the cable holes (A to B) as marked below. 3. With the cable(s) dangling, attach three (3) screws (included in the camera package) to install the L-type wall mount onto the wall. www.acti.com...
- Page 5 2. Connect the network cable to the Ethernet port of the camera. If necessary, connect the other cables (such as power adaptor, DI/DO, etc.) to the corresponding connectors. 3. Align and insert the camera base hooks to the mounting holes. 4. Slide the camera clockwise to secure the hooks to the mount. www.acti.com...
- Page 6 5. Attach three (3) screws (included in the L-type wall mount package) to secure the camera to the mount. Step 3: Access the Camera Live View Refer to the camera Hardware Manual downloadable from the website (www.acti.com) for more information. www.acti.com...
-
Page 7: Safety Information
Do not use attachments not recommended by the video product manufacturer as they may cause hazards. Do not use accessories not recommended by the manufacturer Only install this device in a dry place protected from weather Servicing Do not attempt to service this video product yourself. Refer all servicing to qualified service personnel. www.acti.com... - Page 8 Safety Check Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine if the video product is in proper operating condition. www.acti.com...
