ACTi ACM-3401 Specifications

Fi xe d D o m e C am e ra
ACM-3401/ACM-3411
PHOTO INDICATION
1
2
3
1 Ethernet port
2 DC 12V Power Input
3 Audio Input / Output
ACCESSORY OPTIONS
Lens
PLEN-0112
Dome Cover
PDCX-0101
w w w . a c t i . c o m
4
5
4 Reset button
5 Digital Input / Output
Fixed Iris, F2.0, 2.4 mm, 108.7°
(For ACM-3401 only)
3-inch, smoke, non-vandal proof
* Latest product information: www.acti.com/product/
* Accessory information: www.acti.com/accessory/
• 1/3" Aptina Progressive Scan CMOS
• Day and night function with mechanical IR cut filter
(ACM-3411 )
• Minimum illumination 0.5 Lux at F1.0 (ACM-3401) /
0.05 Lux at F1.0 (ACM-3411)
• Built-in f4.2 mm / F1.8 Megapixel fixed lens (It is possible to
replace the bundled lens with the optional lens for ACM-3401)
• 8 fps at 1280 x 1024 resolution
• Selectable MPEG-4 SP, MJPEG compressions
• Two-way audio
• Video motion detection
• Powered by PoE Class 3 / DC 12V

DIMENSION DIAGRAM

Popular Mounting Solutions
Surface Accessories not required
Wall PMAX-0308
Pendant PMAX-0101
PMAX-0103
Corner PMAX-0101
PMAX-0303
PMAX-0402
Pole PMAX-0101
PMAX-0303
PMAX-0502
Flush PMAX-1006
* For more mounting solutions, please refer to Mounting Accessory section of Buyer's
Guide or Project Planner v2.0 on www.acti.com
Megapixel IP PoE Fixed
Dome / Megapixel IP IR
D/N PoE Fixed Dome
Unit: mm [inch]
+
+ +
+ +
100830
