- Page 1 Indoor Mini Dome & Indoor Mini Fisheye Dome Mounting on a Wall with Flat Surface (Face Forward) Installation Guide For Models: D9x / E9x / ACM-3701E 2014/01/09...
-
Page 2: Table Of Contents
Step 6: Adjust the Viewing Angle and Focus .......... 6 Step 7: Close the Dome Cover ..............6 Appendices ................. 7 How to Access the Camera Live View ............7 How to Adjust the Viewing Angle and Focus ........15 Safety Information ............17 www.acti.com... -
Page 3: Installation Procedures
1. Using the bundled hex screwdriver, loosen the three (3) screws to remove the dome cover. 2. If the network cable will be routed along the surface, slide the cable exit tab from the dome cover. Otherwise, skip this step. www.acti.com... -
Page 4: Step 2: Route The Network Cable
(3) screws included in the camera package. Or, use the drill template to mark and drill the screw holes, insert the plastic plugs and install the camera using the three (3) supplied screws. NOTE: Make sure the screws are flat on the plate. www.acti.com... -
Page 5: Step 4: Connect The Cable
Ethernet Cable AC Power (Data + Power) Source Camera Step 5: Access the Camera Live View How to Access the Camera Live View on page 7 for more information on how to access the Live View of the camera. www.acti.com... -
Page 6: Step 6: Adjust The Viewing Angle And Focus
1. Align cable tab side of the dome cover to the direction of the network cable. 2. Tighten the three (3) screws using the supplied hex screwdriver to attach the dome cover. Final installation should look similar to the illustration below. www.acti.com... -
Page 7: Appendices
PC. The user, however, might not know the IP address of the camera yet. It is necessary to know the IP address of the camera in other to be able to access it by using a Web browser. www.acti.com... - Page 8 – by using IP Utility. The IP Utility is a light software tool that can not only discover the cameras, but also list lots of valuable information, such as IP and MAC addresses, serial numbers, firmware versions, etc, and allows quick configuration of multiple devices at the same time. www.acti.com...
- Page 9 Installation Guide The IP Utility can be downloaded for free from http://www.acti.com/IP_Utility With just one click, you can launch the IP Utility and there will be an instant report as follows: You can quickly see the camera model in the list. Click on the IP address to automatically launch the default browser of the PC with the IP address of the target camera filled in the address bar of the browser already.
- Page 10 Installation Guide Manually adjust the IP address of the PC: In the following example, based on Windows 7, we will configure the IP address to 192.168.0.99 and set Subnet Mask to 255.255.255.0 by using the steps below: www.acti.com...
- Page 11 In such case, please plug in only one camera at a time, and change its IP address by using the Web browser before plugging in the next one. This way, the Web browser will not be confused about two devices having the same IP address at the same time. www.acti.com...
- Page 12 When using Internet Explorer browser, the ActiveX control for video stream management will be downloaded from the camera directly – the user just has to accept the use of such control when prompted so. No other third party utilities are required to be installed in such case. www.acti.com...
- Page 13 HTTP port of the camera is 80, which can be omitted from the address for convenience. Before logging in, you need to know the factory default Account and Password of the camera. Account: Admin Password: 123456 www.acti.com...
- Page 14 Installation Guide To check the firmware version through the Web Configurator, access the Setup page and click System > System Info. For further operations, please refer to the Firmware User Manual downloadable from the website (www.acti.com). www.acti.com...
-
Page 15: How To Adjust The Viewing Angle And Focus
The following procedures are not applicable to E96 (Mini Fisheye Dome) cameras. 1. Loosen the three (3) screws to remove the dome cover. 2. Based on the live view from the camera, adjust the viewing angle with pan and tilt direction (for Mini Dome models only). www.acti.com... - Page 16 Attach the focus tuner (included in the camera package) on the lens and adjust the focus of the lens. b. Remove the lens focus tuner. 4. Attach the dome cover to the camera and tighten the three (3) screws. www.acti.com...
-
Page 17: Safety Information
Do not use attachments not recommended by the video product manufacturer as they may cause hazards. Do not use accessories not recommended by the manufacturer Only install this device in a dry place protected from weather Servicing Do not attempt to service this video product yourself. Refer all servicing to qualified service personnel. www.acti.com... - Page 18 Safety Check Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine if the video product is in proper operating condition. www.acti.com...
