- Page 1 3-Axis Indoor IR Dome (with DC 12V / PoE) ACM-3210 series Ver. 081016 Hardware User’s Manual...
-
Page 2: Trademarks
PRECAUTIONS Read these instructions All the safety and operating instructions should be read before the product is operated. Heed all warnings All warnings on the product and in the instruction manual should be adhered to. The symbol indicates the following items, please carefully read the description next to each symbol. - Page 3 and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
-
Page 4: Table Of Contents
Table of Contents PRECAUTIONS________________________________________________ 0-1 Trademarks ________________________________________________________________ 0-1 Liability ___________________________________________________________________ 0-1 FCC/CE Regulation __________________________________________________________ 0-1 INTRODUCTION ______________________________________________ 1-1 Package Contents _______________________________________________ 1-1 Features and Benefits ____________________________________________ 1-2 Safety Instructions ______________________________________________ 1-4 Physical Description _____________________________________________ 1-6 Basic Connections _______________________________________________ 1-8 Installation Procedure ___________________________________________ 1-9 1.6.1 Ceiling Mount _______________________________________________________ 1-9 1.6.2... -
Page 5: Introduction
INTRODUCTION 1.1 Package Contents ACM-3210 series Power Adaptor (Option) (DC12V / PoE) Product CD Accessory Warranty Card Drill Template Drill template... -
Page 6: Features And Benefits
1.2 Features and Benefits This IP device is a cutting-edge digital video transmission device. It can compress and transmit real time images with outstanding images quality (D1, 720x480) at reasonable bandwidth through a standard TCP/IP network. That is because it is Ethernet ready and has the powerful ARM9 SoC and the MPEG-4 compression ASIC inside. - Page 7 utilize the existing PC to be a digital video recorder. Schedule recording and manual recording keep every important image recorded in the local hard disk. Reliable and accurate motion detection with instant warning makes you responsive in every condition. Quick and simple search and playback function lets you easily find the images you want.
-
Page 8: Safety Instructions
1.3 Safety Instructions Don’t use the power supply with other voltages This device is likely to be damaged or damage other equipments / personnel, if you use a power supply with different voltage than the one included with this device. All warranty of this product will be voided in the situations above. - Page 9 If the video product does not operate normally by following the operating Instructions in this manual. Adjust only those controls that are covered by the instruction manual as an improper adjustment . Other controls may result in damage and will often require extensive work by a qualified technician to restore the video product to its normal operation.
-
Page 10: Physical Description
1.4 Physical Description Ethernet Port The IP device connects to the Ethernet via a standard RJ45 connector. Supporting NWAY, this IP device can auto detect the speed of local network segment (10Base-T/100Base-TX Ethernet). Power Input If your power input is DC12V. Please follow the description on the connector to connect to power. - Page 11 Step 2: Press and continue to hold the Reset Button. Reconnect the power cable while continuing to hold the reset button. Step 3: Keep holding the reset button depressed for a while, release the reset button. The unit will start up with factory default settings.
-
Page 12: Basic Connections
1.5 Basic Connections Follow the procedures below to connect the IP device to the respective apparatuses. 1. Connect an analog monitor to IP device video out (BNC connector). 2. Connect the power adaptor to IP device 3. Connect IP device’s ethernet port to an Ethernet (RJ45 connectors). If your IP device has PoE built-in, you can regard it as a PD and connect it directly to a PSE device like PoE switch. -
Page 13: Installation Procedure
1.6 Installation Procedure 1.6.1 Ceiling Mount 1.6.1.1 Use the drill template, and drill a hole with φ35 on the ceiling 1.6.1.2 Tighten the plate to ceiling with M4*20 screws... - Page 14 1.6.1.3 Connect cables through the hole on the ceiling and plate, or on the side of casing 1.6.1.4 Fasten the camera to ceiling 1-10...
-
Page 15: Wall Mount
1.6.2 Wall Mount 1.6.2.1 Tighten wall mount bracket to the wall by 3 PAN Head Tapping screws 3-PAN HEAD SCREW TAPPING 1.6.2.2 Tighten the plate to wall mount bracket with M4*10 screws, and connect all necessary cables through the hole on the plate and wall mount kit 2-FLAT HEAD SCREW TAPPING(M4x10 1-11... - Page 16 1.6.2.3 Note: that there’s a triangle mark on both plate and wall mount kit. Those triangle marks need to fix on the same direction. 1.6.2.4 Fasten the camera to wall mount kit by turning clockwise direction 1-12...
-
Page 17: Camera Adjustment
1.6.3 Camera Adjustment 3-axis design enables easily adjustment in every angle 1.6.3.1 X-axis – Panning View with angle range 0°~360° 1.6.3.2 Y-axis – Tilting View with angle range 0°~180° 1-13... - Page 18 1.6.3.3 Z-axis – Rotating View with angle range 0°~360° 1-14...
-
Page 19: Product Specification
1.7 Product Specification 1-15...
