Solar panel
Solar-powered Transmitter:
Notes:
Solar panel
Model WS-6010U
Solar Station
QUICK SETUP GUIDE
Remote transmission of outdoor temperature and humidity to the
Solar Station by 915 MHz signals
LCD will automatically alternate and display the outdoor
temperature and humidity data
Recharge batteries by solar-powered cells
Wall mounting case
1
Wall Mount
Location
Battery
compartment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS-6010U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for La Crosse WS-6010U

Summary of Contents for La Crosse WS-6010U

  • Page 1 Model WS-6010U Solar Station QUICK SETUP GUIDE Wall Mount Location Solar panel Battery compartment Solar-powered Transmitter:  Remote transmission of outdoor temperature and humidity to the Solar Station by 915 MHz signals  LCD will automatically alternate and display the outdoor temperature and humidity data ...
  • Page 2  The solar-powered temperature transmitter uses solar cells to charge the rechargeable batteries (2 x AAA rechargeable batteries; included).  The rechargeable batteries cannot be replaced. SOLAR TRANSMITTER OPERATION MODES Important: Users need to press the reset key to activate the solar transmitter and link the transmission to the Solar Station (receiver).

  • Page 3: Initial Setup

     If the solar transmitter is placed into a dark environment for 72 hours, will goes into Stop mode.  If the user cover the solar cell for 10 seconds and press the reset button, "StP" will be displayed on the LCD. Then the transmitter enters STOP mode. Idle Operation Mode: ...
  • Page 4 Open the battery compartment, and MAKE SURE that the battery switch is in the BATTERY position (not the SOLAR position). Battery switch in the BATTERY position Now locate the battery insulator tab, and gently pull to remove it. Slide the battery switch to the SOLAR position Battery switch in the SOLAR position Continue to section titled “Setup After Changing/Installing the Battery in the Solar Station”...
  • Page 5 Note: For best performance, batteries should be replaced at least once every 2 years to maintain the best running accuracy. Ensure that the batteries used are new and the correct size. Use switch to select which type of battery will be used before inserting the battery into the compartment...

  • Page 6: To Set The Time

    Rechargeable Alkaline Primary Alkaline battery switch position battery switch position Please help in the preservation of the environment and return used batteries to an authorized depot. SETUP AFTER CHANGING/REPLACING THE BATTERY IN THE SOLAR STATION After powering up the Solar Station, all LCD segments will light up briefly and it will show the time (12:00), indoor temperature, date, and indoor humidity.

  • Page 7: Solar Mode

    The hour digits will start flashing. Set the desired hours by pressing and releasing the + key followed by pressing the SET key. Now the minute digits will start flashing. Set the desired minutes by pressing and releasing the + key. If the + key is held, the units will increase by 5.
  • Page 8  The Solar Station will not perform any operation and the LCD will also be OFF.  Press any key to wake up the Solar Station and to re-activate the transmission with the solar transmitter. MIN/MAX: Press and release the PLUS button to view: ...

  • Page 9: Wall Mounting

    915MHZ RECEPTION CHECK FOR OUTDOOR SOLAR TRANSMITTER The Solar Station will receive the outdoor data every 48 seconds. If the temperature data is not being received 2 minutes after setting up (or the display shows “- - -”), then please check the following points: The distance of the Solar Station or outdoor transmitter should be at least 6 feet (2 meters) away from any interfering sources such as computer monitors or TV sets.

  • Page 10: Warranty Information

    Warranty service can only be performed by a La Crosse Technology, Ltd authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center.
  • Page 11 La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above. All replaced parts and products become the property of La Crosse Technology, Ltd and must be returned to La Crosse Technology, Ltd.
  • Page 12 La Crosse Technology 2817 Losey Blvd. S. La Crosse, WI 54601 The complete instruction manual is available at: www.lacrossetechnology.com/support Le manuel d'instruction complet est disponible sur: www.lacrossetechnology.com / support El manual de instrucciones completo está disponible en: www.lacrossetechnology.com / support All rights reserved.
