Solar Powered Wireless Humidity/Temperature Station
Set keys
Stands
FEATURES:
Receives wireless outdoor temperature
Solar cell powers the included 2 "AA" rechargeable alkaline batteries
Works with regular alkaline batteries with a flip of a switch
Stores solar power for continuous operation
High-efficiency modern solar panel maintains full charge with minimal light
Outdoor/Indoor temperature with MIN / MAX records (°F)
Indoor humidity
12 Hour time display
Low battery indicators
Use the 2 "AA" Rechargeable Alkaline batteries (included) OR 2 "AA" Alkaline
batteries required (not included). No need to change batteries when using
rechargeable alkalines because they receive power from the solar cell. 2 Display mode
options: (1) Top displays IN/OUT temperature. Bottom displays MIN/MAX records,
time, and humidity. (2) Top displays indoor temperature and humidity. Bottom displays
outdoor temperature, time and MIN/MAX records.
Model WS-8120
(Weather Station)
QUICK SETUP GUIDE
Wall mount
LCD display
Battery
cover
1
Solar panels
%
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for La Crosse WS-8120
Summary of Contents for La Crosse WS-8120
- Page 1 Model WS-8120 Solar Powered Wireless Humidity/Temperature Station (Weather Station) QUICK SETUP GUIDE Wall mount Solar panels LCD display Set keys Battery cover Stands FEATURES: Receives wireless outdoor temperature Solar cell powers the included 2 "AA" rechargeable alkaline batteries ...
- Page 2 INITIAL SETUP (USING INCLUDED SOLAR RECHARGEABLE BATTERIES FROM THE FACTORY) Step #1: Open battery compartment on the back of the Weather Station and make sure that the battery switch under the battery compartment is positioned to the left. If it is not, please slide the switch to the left before proceeding.
-
Page 3: Reset Key
Transmits outdoor temperature to indoor receiver using 915 MHz signals 200 FT. wireless transmission range (open air). Built-in rechargeable alkaline power cells store solar power for continuous operation. No batteries necessary (internal power cells cannot be replaced;... -
Page 4: Idle Mode
(2) IDLE MODE: If the battery voltage drops below 2.4V, it commences IDLE MODE; the LCD turns off and it does not measure / transmit weather data. It checks the brightness level of the surrounding environment every 5 seconds. ... -
Page 5: Low Battery Indicator
LCD will automatically turn ON if the environment is bright enough. No information will be displayed when the LCD is OFF, but all the settings and operations will remain, except for the temperature and humidity measurements. Enter the program menu and turn SOL to OFF to disable this power save feature. If solar mode setting is OFF: ... - Page 6 The maximum transmission range is 200 feet (60.96 m) from the outdoor transmitter to the Solar Station (in open space). However, this depends on the surrounding environment and interference levels. If no reception is possible despite the observation of these factors, all system units have to be reset (see “TO REPLACE BATTERIES IN THE WEATHER STATION”...
-
Page 7: Positioning The Weather Station
SETUP AFTER INITIAL START-UP / REPLACING THE BATTERIES After powering up the Weather Station, all LCD segments will light up briefly and it will show the time (12:00), indoor temperature, date, and indoor humidity. After the batteries are inserted, the Weather Station will start receiving data signal from the Sensor. -
Page 8: Specifications
Measured period: every 48 seconds WARRANTY INFORMATION La Crosse Technology, Ltd provides a 1-year limited warranty on this product against manufacturing defects in materials and workmanship. This limited warranty begins on the original date of purchase, is valid only on products purchased and used in North America and only to the original purchaser of this product. - Page 9 La Crosse Technology, Ltd or La Crosse Technology, Ltd’s authorized service center. La Crosse Technology, Ltd will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specified above.
- Page 10 For warranty work, technical support, or information contact: La Crosse Technology 2817 Losey Blvd. S. La Crosse, WI 54601 The complete instruction manual is available at: www.lacrossetechnology.com/support Le manuel d'instruction complet est disponible sur: www.lacrossetechnology.com/support El manual de instrucciones completo está disponible en: www.lacrossetechnology.com/support...
