TEMPERATURE STATION
Model WS9008UIT
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this innovative 915MHz Temperature
Station which displays indoor and outdoor temperature. To enjoy the full
benefits of this innovative product, please read this operating manual.
« Instant Transmission+» is the up and coming state-of-the-art new
wireless transmission technology, exclusively designed and developed
by LA CROSSE TECHNOLOGY.
"IT +" offers you an immediate update of all your outdoor data measured
from the transmitters: follow your climatic variations in real-time!
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for La Crosse WS9008UIT
Summary of Contents for La Crosse WS9008UIT
- Page 1 « Instant Transmission+» is the up and coming state-of-the-art new wireless transmission technology, exclusively designed and developed by LA CROSSE TECHNOLOGY. “IT +” offers you an immediate update of all your outdoor data measured from the transmitters: follow your climatic variations in real-time!
- Page 2 FEATURES: The Temperature Station Hanging Hole Battery Compartment Cover Display Foldout Function Stand Keys Temperature display in degrees Celsius (°C) or Fahrenheit (°F) selectable Indoor and Outdoor temperature display with MIN/MAX recording...
-
Page 3: The Outdoor Temperature Transmitter
All indoor and outdoor MIN/MAX recordings can be reset seperately Low battery indicator Wireless transmission at 915 MHz Outdoor signal reception intervals at every 27.5 seconds Table standing or wall mounting The Outdoor Temperature Transmitter Remote transmission of outdoor temperature to Temperature Station by 915 MHz Shower proof casing Wall mounting case... - Page 4 SETTING UP: NOTE: The Temperature Station will receive one outdoor transmitter only. First, insert the batteries into the Temperature transmitter. (see “Install and replace batteries in the Temperature transmitter“). Immediately after and within 1 minute, insert the batteries into Temperature Station (see “Install and replace batteries in the Temperature Station”).
- Page 5 INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE STATION The Temperature Station uses 2 x AA, IEC LR6, 1.5V batteries. To install and replace the batteries, please follow the steps below: Remove the cover at the back of the weather station. Insert batteries observing the correct polarity (see marking).
-
Page 6: Battery Change
Insert the batteries, observing the correct polarity (see marking). Replace the battery compartment cover on the unit. Note: In the event of changing batteries in any of the units, all units need to be reset by following the setting up procedures. This is because a random security code is assigned by the transmitter at start-up and this code must be received and stored by the Temperature station in the first 3 minutes of power being supplied to it. -
Page 7: Function Keys
FUNCTION KEYS: Temperature Station: The Temperature Station has 2 easy to use function keys. MIN/MAX key IN/OUT key IN/OUT key To toggle between the indoor and outdoor temperature display Press and hold to toggle between the temperature display of degree Celsius (°C) and Fahrenheit (°F) MIN/ MAX key To toggle between the MIN/MAX indoor and outdoor temperature display... -
Page 8: Lcd Screen And Settings
Press and hold to reset the MIN/MAX outdoor temperature records to the current outdoor temperature (if the outdoor temperature is displayed) LCD SCREEN AND SETTINGS: Receiver low battery Transmitter low battery icon Temperature display in ºC or °F Outdoor signal reception icon*... - Page 9 When the outdoor signal is successfully received by the Temperature Station, this icon will be switched on. (If not successful, the icon will not be shown in LCD) So user can easily see whether the last reception was successful (icon on) or not (icon off). DISPLAY OF INDOOR TEMPERATURE READING AND INDOOR MIN/MAX RECORDS: Press the IN/OUT key to view the current indoor temperature...
- Page 10 DISPLAY OF OUTDOOR TEMPERATURE READING AND OUTDOOR MIN/MAX RECORDS: Press the IN/OUT key to view the current outdoor temperature Press the MIN/MAX key to view the MIN record Press again the MIN/MAX key to view the MAX record. Press the MIN/MAX once more to return to current outdoor temperature. Outdoor data icon Outdoor...
-
Page 11: Resetting The Min/Max Records
RESETTING THE MIN/MAX RECORDS When the indoor temperature is displayed, press and hold the MIN/MAX key for about 2 seconds to reset the indoor MIN/MAX temperature records to the current indoor temperature. When the outdoor temperature is displayed, press and hold the MIN/MAX key for about 2 seconds to reset the outdoor MIN/MAX temperature records to the current outdoor temperature. - Page 12 The distance of the Temperature Station or transmitter should be at least 1.5 to 2 metres away from any interfering sources such as computer monitors or TV sets. Avoid positioning the Temperature Station onto or in the immediate proximity of metal window frames.
-
Page 13: To Wall Mount
POSITIONING THE TEMPERATURE STATION: The Temperature Station has been designed to be hung onto a wall or free standing. To wall mount Choose a sheltered place. Avoid direct rain and sunshine. Before wall mounting, please check that the outdoor temperature values can be received from the desired locations. - Page 14 POSITIONING THE TEMPERATURE TRANSMITTER: The Transmitter is supplied with a holder that may be attached to a wall with the two screws supplied. The Transmitter can also be positioned on a flat surface by securing the stand to the bottom of the Transmitter.
-
Page 15: Care And Maintenance
CARE AND MAINTENANCE: Extreme temperatures, vibration and shock should be avoided as these may cause damage to the unit and give inaccurate forecasts and readings. Precautions shall be taken when handling the batteries. Injuries, burns, or property damage may be resulted if the batteries are in contact with conducting materials, heat, corrosive materials or explosives. -
Page 16: Specifications
Do not expose the units to extreme and sudden temperature changes, this may lead to rapid changes in forecasts and readings and thereby reduce their accuracy. SPECIFICATIONS: Temperature measuring range: Indoor -9.9°C to +59.9°C with 0.1°C resolution/ +14.2°F to +140°F with 0.2°F resolution (“OF.L”... -
Page 17: Liability Disclaimer
Temperature transmitter 2 x AAA, IEC, LR3 1.5V Battery life cycle (Alkaline batteries recommended): Temperature station Approximately 24 months Temperature transmitter Approximately 12 months Dimensions (L x W x H): Temperature station 74 x 29.1 x 98mm Temperature transmitter 32.4 x 14.1 x 86.5mm LIABILITY DISCLAIMER: Please ensure that all discarded packaging and unwanted electrical items are discarded in a correct and responsible manner. - Page 18 Distributed by: Sontax Australia Phone: 1800 653 238 Email: sales@sontax.com.au Website: www.sontax.com.au WS9008UIT Printed in China...
