TOUCH SCREEN WEATHER STATION
MODEL WS-3650

Operation Manual

« Instant Transmission+» is the up and coming state-of-the-art new wireless
transmission technology, exclusively designed and developed by LA
CROSSE TECHNOLOGY.
"IT +" offers you an immediate update of all your outdoor data measured
from the transmitters: follow your climatic variations in real-time!
28
