EXTERNAL CONTROL

One of the new Core Features of the Soundblox 2 line of effects pedals is
the addition of the Multi-Function Input. The Multi-Function input is an
intelligent control input that can accept both digital and analog control
signals. The Multi-Function input replaces the Sensor Input on previous
Soundblox pedals. The MULTI-FUNCTION input can connect to wired or
wireless Hot Hand accessories, a Source Audio Expression Pedal, or a
future Source Audio MIDI interface that will enable full MIDI I/O access to
the pedal.
GUITAR IN GUITAR OUT
MULTI- MULTI-
FUNCTION FUNCTION
9V DC
IN OUT
18 | External Control
