Control Assign - Source Audio Soundblox 2 User Manual

TIME
OPTION
SELECT

CONTROL ASSIGN

By default, the expression pedal and Hot Hand inputs are assigned to
control the TIME parameter. This can easily be changed to control any
other knob parameter or an additional REVERB SEND parameter. To as-
sign control to a knob parameter:
1. Select the desired external control option: EXP for expression pedal,
HH for Hot Hand.
2. Press and hold the CONTROL INPUT (A) button until the LED begins
to blink slowly.
3. Set the low position of the desired knob, for example MIX (B), to the
lowest setting you would like to use.
4. Press the CONTROL INPUT button again and the LED will now blink
rapidly.
5. Set the desired high position you would like to use.
6. Press the CONTROL INPUT button to complete the assignment. The
LED will blink 3 times to indicate the process is complete.
20 | External Control
E-DOME
ARENA
STAGE
CLUB
PRE-DELAY
(OUTPUT)
ROOM
DIFFUSE
(RATE)
BASS
(DEPTH)
1
OPTION
DIMENSION REVERB
PLATE 1
PLATE 2
SPRING 1
SPRING 2
MODVERB
METAL BOX
ECHO
TREBLE
MIX
DRY WET
HH
MIDI
EXP
CONTROL
INPUT
2
B
A
