Source Audio Soundblox 2 User Manual page 22

A
TIME
B
OPTION
SELECT
1. Select the expression pedal input and assign it to REVERB SEND as
described above.
Select a desired reverb type (ex. ARENA) (A) and turn up the TIME (B)
2.
knob to create a long tailing and sustained effect.
Put the expression pedal in toe down position and play into the effect.
3.
The sound will now begin to reverberate.
Next, move the expression pedal into the heel down position to turn
4.
down the REVERB SEND.
Now play again and the input will stay dry and not go into the reverb
5.
effect.
22 | External Control
E-DOME
ARENA
STAGE
CLUB
PRE-DELAY
(OUTPUT)
ROOM
DIFFUSE
(RATE)
BASS
(DEPTH)
1
OPTION
DIMENSION REVERB
PLATE 1
PLATE 2
SPRING 1
SPRING 2
MODVERB
METAL BOX
ECHO
TREBLE
MIX
DRY WET
HH
MIDI
EXP
CONTROL
INPUT
2
