Operation

Front Panel

The front-panel Smart Touch button allows you a direct control over KVM switching
operation. Simply press the button to switch to the respective PC port. For more
operation about Smart Touch button, please refer to "Quick Reference Sheet".

Hotkey Control

A Hotkey command is a short keyboard sequence for selecting a computer, activating
computer scan, etc. A hotkey sequence starts with two left <ScrLk> keystrokes
(successively within 2 seconds) followed by one or two more keystrokes. A built-in
tone generator creates a high-pitch beep for correct hotkey command; otherwise, one
low-pitch beep is generated for errors and the bad key sequence will not be forwarded
to the selected computer.
Please refer to the "Quick Reference Sheet" for available commands
Command
Select PC Port
(Jointly select
PC port/ hub
port control/
audio&mic,
if binding is
enabled)
Select Hub Port
Control (Jointly
select PC and
hub port control,
if binding is
enabled)
Instruction Manual
Quick Reference Sheet
Hotkeys
ScrLk + ScrLk +
(1~2/1~4)
ScrLk + ScrLk +
F1~F2/F1~F4
Front-Panel
Smart Touch
Button
Touch the
corresponding
button to select
the active PC port.
Touch the button
to toggle the
specific PC+USB
hub port control.
(It works only if
PC port/ hub port
control binding is
enabled.)
5
Description
Select the PC port
Move Hub Port
(1~2 / 1~4)
