2
HDMI Input
mapping area
1.
Scan: Press the "scan" button, select "scan", then select the detected port and
click OK
2.
Setting: Press the "setting" button then press the "get" button to read back the
device ID. Press the "set" button to write the device ID
1
3
4
5
6
Status indicator
HDMI Output
mapping area
