- Page 1 8x8 HDMI 18G Matrix with Audio User Manual Eng li sh Benutzerhandbuch Deutsch Manuel Utilisateur Français Manuale Italiano No. 38248 lindy.com © LINDY Group – FIFTH EDITION (January 2021)
- Page 3 Please ensure any adapters are firmly secured and locked in place before inserting into a wall socket Introduction Thank you for purchasing the Lindy 8x8 HDMI 18G Matrix with Audio. This product has been designed to provide trouble free, reliable operation. It benefits from both a LINDY 2-year warranty and free lifetime technical support.
- Page 4 User Manual English Specification ▪ Input: 8 x HDMI (Female), Output: 8 x HDMI (Female), 8 x SPDIF (Female), Control: RS-232 (Female), RJ45 (Female), 3.5mm (Female) ▪ Supported Audio Formats: LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X ▪...
- Page 5 User Manual English 4. Power and the Power LED: Hold down this button to power the matrix on or off. The LED will be illuminated green when the matrix is powered on. The LED will be illuminated red when the matrix is in standby.
- Page 6 User Manual English EDID Management Table EDID Mode EDID Resolution 1280x720, 60Hz, 4:4:4, 8bit. 2 Channel audio, 24-bit, 48khz. 1920x1080, 60hz, 4:4:4, 8bit. 2 Channel audio, 24-bit, 48khz. 1920x1080, 60hz, 4:4:4, 8bit. 6 Channel audio, 24-bit, 192khz. Dolby Digital and DTS audio.
- Page 7 User Manual English Control IR Remote The output must be selected first, then the input port to display the set layout. Power Button: Power on the matrix or press to set the matrix to standby. Input 1/2/3/4/5/6/7/8: Press to select the required Input port. <...
- Page 8 User Manual English Matrix 1. Select within the Green Input area and then select Input to configure to Output A. All other Output ports follow the same rule. EDID 1. Select the required EDID setting and select Set to configure this to a required Input port.
- Page 9 RS-232 to USB cable. Then open a serial command tool to enter all required commands. This can be found at the local Lindy website under Downloads of “38248”. Please see below for the RS-232 Pin Out for reference:...
- Page 10 User Manual English RS-232 Command List Serial Port Protocol: Baud rate(default): 19200 Data bits: 8 Stop bits: 1 Check bit: 0 RS-232 Command Function Feedback s x av y! Switch x channel input to y channel output AV x -> y s x all! Switch x channel input to all channel output X to all...
- Page 11 Reboot the matrix Rboot s factory reset! Restore the matrix to factory settings Factory reset r type! Query the model of the matrix Lindy 38248 r version! Query the firmware version A aa.bb-aa.bb-aa.bb r status! Query the status of matrix A aa.bb-aa.bb-aa.bb.cc.dd...
- Page 12 Standard IEC 60950-1 or 60065 or 62368-1. LINDY Herstellergarantie – Hinweis für Kunden in Deutschland LINDY gewährt für dieses Produkt über die gesetzliche Regelung in Deutschland hinaus eine zweijährige Herstellergarantie ab Kaufdatum. Die detaillierten Bedingungen dieser Garantie finden Sie auf der LINDY Website aufgelistet bei den AGBs.
-
Page 13: Recycling Information
Geräte müssen den Sammel- und Rückgabesystemen zugeführt werden! Dort werden sie kostenlos entgegen genommen. Die Kosten für den weiteren Recyclingprozess übernehmen die Gerätehersteller. LINDY bietet deutschen Endverbrauchern ein kostenloses Rücknahmesystem an, beachten Sie bitte, dass Batterien und Akkus den Produkten vor der Rückgabe an das Rücknahmesystem entnommen werden müssen und über die Sammel- und Rückgabesysteme für Batterien separat entsorgt werden müssen.
