ACTi ACM-1431 Brochure & Specs

I P B u l l e t C a m e r a
ACM-1431/ACM-1432
* The bracket needs to be purchased separately.
41 w w w . a c t i . c o m
1 DC 12V / AC 24V Power Input
2 Audio Input / Output & Video Output
3 Reset Button

DIMENSION DIAGRAM

* All specifications are subject to change without notice.
* All brand names and registered trademarks are the property of their respective owners.
Outdoor IP IR Bullet Camera
• 1/3" Sony SuperHAD CCD
• Day and night function with Mechanical IR Cut Filter
• Integrated f3.8 ~ 9.5 mm F1.2 varifocal lens
• 0 Lux (IR LED ON)
• Backlight Compensation, Auto Iris Control, Auto White
Balance supported
• Selectable MPEG-4 / MJPEG compression
• CIF up to Full D1 resolution at 30/25 FPS
• Multi-stream with variable frame rate in the same
compression
• Two-way audio supported
• Hardware motion detection
• Hybrid analog and ethernet video output with 540 TV
lines
• DC 12V or Power over Ethernet (IEEE 802.3af)
supported(ACM-1431),or AC 24V power source
supported(ACM-1432)
• IP66 weatherproof supported
1
2
3
4
5
4 Ethernet Port
5 Power LED Indicator
Unit: mm [inch]
