ACTi ACM-1231 Specifications

M e g a p i x e l I P C a m e r a
ACM-1231/ACM-1232
* The bracket needs to be purchased separately.
23 w w w . a c t i . c o m
1 DC 12V / AC 24V Power Input
2 Audio Input / Output
3 Reset Button

DIMENSION DIAGRAM

* All specifications are subject to change without notice.
* All brand names and registered trademarks are the property of their respective owners.
Megapixel Outdoor IP IR Bullet Camera
• 1/3" Micron Progressive Scan CMOS
• Day and night function with Mechanical IR Cut Filter
• Integrated f3.3 ~ 12 mm / F1.6 Megapixel varifocal lens
• 0 Lux (IR LED ON)
• Selectable MPEG-4 SP / MJPEG compression
• Up to SXGA resolution at 8 FPS
• Multi-stream with variable frame rate in the same
compression
• Shutter Speed, White Balance, Exposure, Gain
Controls supported
• Two-way audio supported
• Hardware motion detection
• DC 12V or Power over Ethernet (IEEE 802.3af)
supported(ACM-1231), or AC 24V power source
supported (ACM-1232)
• IP66 weatherproof supported
1
2
3
4
4 Ethernet Port
Unit: mm [inch]
