ACTi CAM-5100 Product Specification

I P C a m e r a
CAM-5100/5120
* The lens is not included.
w w w . a c t i . c o m
MPEG-4 compression gives a high resolution image quality
The CAM-5100 MPEG-4 IP Camera adopts MPEG-4 Advanced Simple Profile (ASP) compliant compression
technology to perform full D1 (4 CIF) resolution. It utilizes the premium 1/3" SONY color CCD sensor, and has
horizontal resolution of 480 TV lines. The real-time image transmission is 30 fps (720 x 480 pixels, NTSC) and 25
fps (720 x 576 pixels, PAL).
Advanced network technologies enable real-time surveillance
With the LAN and WAN ports built-in, the CAM-5100 applies QoS (Quality of Service, IEEE 802.1Q) technology to
fully utilize the network bandwidth. CAM-5100 supports automatic (or manual) frame rate control for concurrent
video streams accessing at different network bandwidth.
With advanced MPEG-4 ASP compliant video compression and QoS-enabled streaming, the CAM-5100 delivers
smooth analog-video like transmission over LAN or WAN to reach true remote video surveillance goal. The
CAM-5100 not only supports DDNS, but also has a built-in web server to enable authorized users to do
live- viewing and adjust the camera setting via remote web browsers.
Sophisticate Design
In addition to support of the DC and a video auto iris lens, the CAM-5100 also has DIP-switch controlled functions
including backlight compensation, auto white balance, auto gain control and flickerless for different application
conditions. With Super Gain Control mechanism, it will switch to color and monochrome picture automatically
(CAM-5120).
1
2
3
1 Composite video output
2 Digital input/output
3 DC 12 V power input
4 WAN port
* All specifications are subject to change without notice.
* All brand names and registered trademarks are the property of their respective owners.
MPEG-4 Real-time Network
Streaming IP Camera with
Day & Night option
• 1/3" SONY Super HAD / Exview HAD with 470K/410K
pixels
• Backlight Compensation, Auto Iris Control, Auto White
Balance supported
• Super Gain Control, IR cut-filter switching mechanism
(CAM-5120)
• Day and night function (CAM-5120)
• MPEG-4 ASP compliant compression
• CIF up to Full D1 resolution at 30/25 FPS
• Dual MPEG-4 video stream output via LAN and WAN
(PPPoE supported) ports at the same time
• QoS enabled (L3) video streaming
4
5
6
5 LAN port
6 Auto Iris lens control port
7 DC level
8 Function DIP switch
7 8
060301
