3.
Secure the drives to the Enclosure tray,
using the provided screws.
4.
Select the operating mode for your hard drive using the DIP Switches
shown below. Once you have set the DIP switches according to the
desired RAID mode, press the Reset Button to save changes.
Reset Button
GUI**
(Requires Software Installation)
** Please see pg. 11 for more details on GUI Mode
Instruction Manual
DIP Switches
RAID Mode
JBOD*
BIG
RAID 0 (Fast)*
RAID 1 (Safe)
RAID/SAFE33*
RAID/SAFE55*
*denotes Port Multiplier requirement
DIP Switches
(GUI mode is shown)
DIP Switch No.
1
ON
ON
OFF
OFF
ON
OFF
ON
4
2
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
OFF
ON
OFF
4
