Table 2: VP-727A-BA Balanced Audio Switcher Rear Panel Features

# Feature
18 INPUT XLR F
Connectors
19
20 PREVIEW XLR
M Connectors
21
22 S/PDIF RCA Connector
23 PROGRAM XLR
M Connectors
24
25 DIP 8
DIP 7
DIP 6
DIP 5
DIPs 3 and 4
DIP 2
DIP 1
26 RS-485 Port
RS-232 Connector
27
28 Power Connector with Fuse
1 By default, DIPs 1 to 7 are set to OFF and DIP 8 is set to ON
2 The ground connection is sometimes connected to the shield of the RS-485 cable. However, usually the ground is not connected
6
Your VP-727A-BA Balanced Audio Switcher
Function
RIGHT Connect to the balanced stereo audio source (from 1 to 8)
LEFT
LEFT Connect to a balanced stereo audio preview acceptor
RIGHT
Connect to a digital audio acceptor
RIGHT Connect to a balanced stereo audio program acceptor
LEFT
Set to ON to operate the VP-727A-BA with the VP-727xl (as slave baud
rate 38,400); else set to OFF
Set to ON to operate the VP-727A-BA with the VP-727 or the VP-727T
(as chain baud rate 115,200); else set to OFF
Set to ON for stand alone (baud rate 9,600); else set to OFF
Set to ON for the fade to follow the transition effect; set to OFF for
separate fade
Set to OFF (default)
Set to ON for RS-485 Line Termination with 120Ω; set to OFF for no
RS-485 Line Termination
Set to ON to upgrade to the latest Kramer firmware (see section 7); set
to OFF for normal operation (the factory default)
Connects to the Kramer VP-727T or the VP-727xl (see section 6.4)
Pin G is for the Ground connection
RS-485
9-pin D-sub connector connects to a PC or Remote Controller via a
null-modem connection
AC connector enabling power supply to the unit
2
; pins B (-) and A (+) are for
