Overview
The Kramer VP-727A-BA is a high performance 8x2 switcher for balanced
stereo audio signals. It switches any input to either the preview or program
output. The VP-727A-BA is an audio companion switcher for the VP-727xl
Universal Presentation Matrix Switcher / Scaler and the VP-727 Universal
Presentation Matrix Switcher / Scaler, and operates in conjunction with them
and the VP-727T Presentation Switcher Control Panel.
The VP-727A-BA features:
• Eight balanced stereo audio inputs on XLR F connectors
• One balanced stereo audio preview output on dual XLR M connectors
• Two balanced stereo audio program outputs on dual XLR M connectors and
a single RCA (S/PDIF) connector
• A selectable headphone connector for preview or program audio outputs
• A front panel lockout
• A TAKE button for executing preview to program switching (with
transition effects)
• An audio-follow-video button when operating in conjunction with the
VP-727xl or the VP-727
• Separate input and output level control
• Fade to mute audio switching
• Separate mute buttons for the preview and program channels
• Bass, treble and balance audio controls
• Audio delay for each input channel
The VP-727A-BA:
• Can be controlled via the front panel buttons and/or RS-232
• Is housed in a 19" 2U rack mountable enclosure
Achieving the best performance means:
• Connecting only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
• Avoiding interference from neighboring electrical appliances, making sure
not to block the ventilation holes, and positioning your VP-727A-BA away
from moisture, excessive sunlight and dust
4
Your VP-727A-BA Balanced Audio Switcher
Figure 1, Table 1 and Table 2 define the VP-727A-BA:
