Starting The Group 3 Test - 3Com EtherLink III ISA User Manual

Table 6-1 Diagnostic Programs
Diagnostic
Program Name
3C503.EXE
3C505.EXE
3C507.EXE
3C508CFG.EXE
3C5X9CFG.EXE
3C523.EXE
3C523TP.EXE
3C527.EXE
3C59XCFG.EXE
3C90XCFG.EXE
The main window of the diagnostic program is displayed.
3 From the Test menu, select Echo Server, and then click Start.
A message confirms that your PC is now set up as an echo server.

Starting the Group 3 Test

Follow these steps to run the Group 3 test on the 3C509B NIC:
1 Start the Configuration and Diagnostic Program on the PC
in which the NIC to be tested is installed.
2 From the Test menu, select Test Setup.
3 Enable the Group 3 test. Select OK and press Enter.
4 Go to the Run Tests dialog box to start the tests.
5 After the test is completed:
a Exit the program on the echo server.
b Exit the Configuration and Diagnostic Program.
Diagnostic Testing Under Windows 3.x
NIC Installed
in the Echo Server
®
EtherLink II or II TP, EtherLink II/16 or II/16 TP
EtherLink Plus ®
EtherLink 16 or EtherLink 16 TP
3Com Red
EtherLink III family
EtherLink/MC
EtherLink/MC TP
EtherLink/MC 32
EtherLink III EISA/PCI bus master family (including Fast
EtherLink NIC running at 10 Mbps)
EtherLink XL and Fast EtherLink XL family of NICs
running at 10 Mbps
6-5
