Controller Lock - Promise Technology FastTrak TX4310 User Manual

FastTrak TX4310 User Manual
1. Go to its function tab under the Physical Drive
icon.
2. Under Schedule, click the Disable radio button.

Controller Lock

The Lock tab displays lock status and enables you to lock or unlock a subsystem
controller. The locking mechanism isolates the controller during maintenance
operations and other periods when you want to avoid interruption from other
users trying to access the logical drives under this controller.
To lock the Controller on the Host PC:
1. Click on the Controller
2. Select the Lock tab in Management View.
3. From the dropdown menu, select a period of time to hold the lock.
The lock time range is 1 to 30 minutes.
4. Click on the Lock button to set the lock.
The lock will release itself automatically at the end of the period you
specified.
5. To release the lock before the scheduled time, click the Unlock button.
icon in Tree View.
60
icon or Logical Drive
