Left; Right - Gateway Notebook Hardware Reference Manual

www.gateway.com

Left

Right

USB ports
Kensington lock slot
S-Video out jack
Component Icon
Kensington™
lock slot
S-Video out jack
USB ports
Monitor port
Modular bay
PC Card slot
Smart card reader
Component Icon
PC Card slot
USB ports
Smart card reader
Monitor port
Description
Secure your notebook to an object by connecting a Kensington cable lock to this
slot.
Plug an S-Video device, such as a television, into this jack. For more information,
see "Viewing the display on a television" on page
Plug USB devices (such as a diskette drive, flash drive, printer, scanner, camera,
keyboard, or mouse) into these ports.
Plug an analog VGA monitor or projector into this port. For more information,
see "Viewing the display on a projector or monitor" on page
Use this bay for a secondary battery, a CD drive, DVD/CD-RW drive, recordable
DVD drive, a diskette drive, or a second hard drive. For more information, see
"Changing modules" on page 23. To determine the type of drive in the modular
bay, examine the drive tray's plastic cover and compare the logo to those listed
in "Identifying drive types" on page
Ventilation fan
Description
Insert one Type II PC Card into this slot. For more information, see
removing a PC Card" on page 27.
Plug USB devices (such as a diskette drive, flash drive, printer, scanner,
camera, keyboard, or mouse) into these ports.
Insert a smart card in this slot.
Identifying features
Modular bay
30.
29.
25.
USB ports
IEEE 1394 port
Modem jack
"Adding and
7
