Extron electronics 13W3-to-VGA Cables and Adapters User Manual

13W3 Connector Pinout
Pin IBM IBM
Power PC RISC Graphics
A1 Red Red
A2 Green Green
A3 Blue Blue
1 ID 2 ID 2
2 ID 3 ID 3
3 Self-test Gnd
4 Dig. Gnd N/C
5 H. sync H. sync
6 ID 0 N/C
7 ID 1 ID 1
8 N/C ID 0 Dig. Gnd
9 V. sync V. sync Dig. Gnd
10 Dig. Gnd Dig. Gnd Dig. Gnd
Part Numbers
This manual covers the following cables and adapters:
Extron Part
13W3M to VGAM cable, 6'
13W3M to VGAM cable, with audio, 6'
13W3M to VGAF adapter
13W3M to VGAF adapter, with hex nut
13W3F to VGAM adapter
13W3F to VGAM cable, 1'
This manual covers the following products, which include one or
more of the cables or adapters listed above:
Extron Part
Adapter kits for VSC 500/ VSC 700 / VSC 900
13W3M–VGAM, 13W3F–VGAM cable kit
13W3M–VGAM, with audio, 13W3F–VGAM cable kit 70-157-03
RGB 190FS
RGB 190FV and cable kit
RGB 192S
RGB 203xi VTG and cable kit
RGB 160xi
RGB192V and cable kit
Extron Electronics, USA Extron Electronics, Europe
1230 South Lewis Street Beeldschermweg 6C
Anaheim, CA 92805 3821 AH Amersfoort
USA The Netherlands
714.491.1500 +31.33.453.4040
www.extron.com
Fax 714.491.1517 Fax +31.33.453.4050
© 2003 Extron Electronics. All rights reserved.
Silicon Sun Sun Dell/
SPARC (older) Hitachi
Red Red Red Red
Green Green Green Green
Blue Blue Blue Blue
Mon 3 Serial read N/C DDC clock
Mon 0 V. sync N/C N/C
C. sync Sense 0 Sense 2 Reserved
H. sync Gnd Gnd DDC Gnd
V. sync C. sync C. sync C. Sync/H. Sync
Mon 1 H. sync N/C DDC data
Mon 2 Serial write N/C V. sync
Sense 1 Sense 1 N/C
Sense 2 Sense 0 Reserved
Gnd Gnd. Serial Gnd
Part #
26-527-23
26-527-03
26-492-03
26-492-04
26-487-03
26-480-03
Part #
70-116-03
70-157-23
60-486-65
42-026-63
60-486-04
42-055-03
42-056-03
42-054-01
Extron Electronics, Asia Extron Electronics, Japan
135 Joo Seng Road, #04-01 Daisan DMJ Building 6F
PM Industrial Building 3-9-1 Kudan Minami
Singapore 368363 Chiyoda-ku, Tokyo 102-0074 Japan
+65.6383.4400 +81.3.3511.7655
Fax +65.6383.4664 Fax +81.3.3511.7656
User's Guide
13W3-to-VGA Cables and Adapters
68-396-03 Rev. A
Printed in the USA
06 03
