1.3 Reading the LED Status:

This table explains the LED indicator status. Refer to
described for ON/OFF and FEED pushbutton switches and AC adaptor socket
LED Indicator
Multi Function:
Dual Green & Yellow
or Red
Yellow
Green and Red

1.4 Attaching Belt Loop System:

The belt loop system consists of two parts:
A knob located on the back part of the printer just above the battery door
A strap with click on connector
To attach the strap insert the knob located at the bottom of the printer into the slot
of the connector. Pull down until you hear a click. The printer is now secure. Place
the loop over your belt. Allow the printer to hang down on the left or right hip.
To release the printer, press in on the two latches on the connector and pull
the knob clear of the slot.
Note: Do not force or pull the printer from the connector without pressing
in on the two latches
State
ON
ON
ON
Table 1 - Reading the LED Status
Figure 4 for the locations
Status
Green --- Printer is on and
ready to receive data.
Yellow --- Indicates low power.
Battery needs recharge.
Red --- Very low power. Printing
not possible.
Yellow --- The battery charger is
charging the battery at a fast
rate. If the battery is below
5.0V, the battery is being
"trickle" charged until the
battery voltage reaches 5.0V,
and then the fast charge rate is
started. The LED will turn Off
when the battery is fully
charged.
Green --- Indicates that MCR is
ready to accept data.
Red --- Indicates a fault
condition or a printer error. The
printer is not ready to accept
data.
Note: Refer to the troubleshooting
guide to determine error or fault
condition.
.
7
