1 . 2 . 2 C h a r g i n g
1 . 2 . 2 C h a r g i n g
Charge the battery by inserting the wall mounted charger line cord into the
printer jack (Refer to
jack on the printer). Then insert the charger plug into an appropriate wall
socket.
The Yellow/Amber charging LED will illuminate indicating that the battery is
being charged
The battery will be fast charged and after about 180 minutes the LED will go
off
To remove the battery cartridge, open the battery door and tip the battery
out of the printer
Note: To ensure a full charge do not operate the printer while charging.
Note: The wall mounted charger is a Class II equipment (
plug configurations comply with most international standards.
Input Voltage/Current
Input Frequency
Output Voltage/Current
)
(
Note: The wall mounted charger is not supplied with
plugs for use in Korea.
Do not use a charger not approved by Extech for use with the
S2500THS. Use of an unapproved charger could damage the battery
!
pack or the printer and will void the warranty.
The battery terminals are well recessed inside the printer. Do not
allow them to contact conductive material since this may create a
!
short circuit which could cause injury or start a fire.
When using the wall mounted charger ensure the socket outlet is close
!
to the printer and easily accessible during the battery recharging
process. Either switch the socket off (if supplied with a socket switch)
or pull out the charger from the socket or disconnect the plug from the
printer in the event of any problems.
t h e B a t t e r y
t h e B a t t e r y
Figure 4
.
on page (20) for the location of the adaptor
S2500T
100-240 VAC/0.5A
47-63 Hz
10VDC/1A
)
. Multiple
