Moisten another cotton swab and rub the swab across the tear bar to remove
any build-up
Note: You may experience dust build-up depending on the environment
and the quality of the paper supply you use. If this occurs, use a can of
compressed air to blow dust and paper debris out of the printer.
4.2 Charging the Printer Battery:
The printer battery is charged using the wall mount adapter provided. Follow these
steps to charge the battery pack.
Plug the power adapter into an appropriate wall socket; then plug the power
adapter cord into Adapter Plug on the side of the printer (see
The yellow CHARGE LED will illuminate, to indicate battery is charging
The Charge LED turns off when battery cartridge is fully charged. It takes
about 180 minutes to fast charge the battery cartridge
To insure full charge, printer should not be operated while the battery is
charging.
4
.
2
.
1
I
m
p
o
r
t
a
n
t
N
4
.
2
.
1
I
m
p
o
r
t
a
n
t
The model 2500THS printers require an adaptor output of 10VDC/1.4A.
The battery Fast-charge is initiated each time the power adapter is
connected to the printer
The fast-charge controller checks the battery's voltage and temperature,
before the start of the fast recharge process. If the battery voltage or the
temperature is outside of the fast-charge limits, the charger defaults to
trickle charge at C/10 or 70mA rate
Optional external battery chargers are available for Extech batteries
4
.
2
.
2
I
m
p
o
r
t
a
n
t
N
4
.
2
.
2
I
m
p
o
r
t
a
n
t
Check for the correct Extech part number for the battery and only order
that part for your new battery
Caution: Risk of explosion if battery is replaced by an incorrect type.
!
Caution: Dispose of used batteries according to instructions in Section
!
4.5
4.3 Verifying Battery Charge State:
It is strongly recommended testing your printer before returning to Extech. Follow
these steps to identify and correct any battery power problem that may be
encountered. These will help to identify that the fault is with the printer and not
some other part of your system.
To test the AC adaptor use a multi-meter and measure the output. Output
should be 10VDC
Press the <ON/OFF> switch and wait until all LED's are off
Insert the AC adaptor plug into the printer. If the amber LED goes on, the
battery is not fully charged but the charge circuit is functioning.
o
t
e
s
o
n
C
h
a
r
g
i
n
N
o
t
e
s
o
n
C
h
a
r
g
i
n
o
t
e
s
o
n
R
e
p
l
a
c
i
n
N
o
t
e
s
o
n
R
e
p
l
a
c
i
g
B
a
t
t
e
r
i
e
s
g
B
a
t
t
e
r
i
e
s
g
B
a
t
t
e
r
i
e
s
n
g
B
a
t
t
e
r
i
e
s
Figure
4)
17
