Fanvil Product User Manual
IP-Gateway
Model: A2
Version：V1.0.90.16
© 2005 Fanvil technology Co,. Ltd
All rights reserved.
This document is supplied by Fanvil Technology Co., Ltd, No part of this document may be
reproduced, republished or retransmitted in any form or by any means whatsoever, whether
electronically or mechanically, including, but not limited to, by way of photocopying, recording,
information recording or through retrieval systems, without the express written permission of
Fanvil Technology Co., Ltd. Fanvil Technology Co., Ltd reserves the right to revise this document
and make changes at any time and without the obligation to notify any person and/or entity of
such revisions and/or changes. Product specifications contained in this document are subject to
change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A2 and is the answer not in the manual?

Questions and answers

Related Manuals for Fanvil A2

Summary of Contents for Fanvil A2

  • Page 1 © 2005 Fanvil technology Co,. Ltd All rights reserved. This document is supplied by Fanvil Technology Co., Ltd, No part of this document may be reproduced, republished or retransmitted in any form or by any means whatsoever, whether electronically or mechanically, including, but not limited to, by way of photocopying, recording, information recording or through retrieval systems, without the express written permission of Fanvil Technology Co., Ltd.

  • Page 2: Safety Notices

    Safety Notices Please read the following safety notices before installing or using this gateway. They are crucial for the safe and reliable operation of the device. Please use the external power supply that is included in the package. Other powers supplies may cause damage to the device, affect the behavior or induce noise.

  • Page 3: Table Of Contents

    ................5 ELCOME TO THE PORT GATEWAY 1.1. Package Contents..................... 5 ................. 6 NDERSTANDING OF PORT GATEWAY 2.1. The positive of A2 two-port gateway ..............6 2.2. Indicator signs ......................7 2.3. Connector description....................7 3. G ....................... 9 ETTING TARTED 3.1.
  • Page 4 5.3.5.5. Account Config......................38 5.3.5.6. Reboot .......................... 39 5.3.6. Security ........................... 40 5.3.6.1. MMI Filter........................40 5.3.6.2. Firewall ......................... 41 5.3.6.3. NAT Config........................42 5.3.6.4. VPN Config........................44 5.3.7. Logout ..........................45 6. A .......................... 46 PPENDIX 6.1. S ........................ 46 PECIFICATION 6.1.1.

  • Page 5: Welcome To The A2 Two-Port Gateway

    2. A group of cable 3. A power adapter NOTE: if you use the non-A2 two-port gateway comes with a power adapter, two-port gateway may cause damage or other injury. Specifications for the power adapter may different between the different shipment areas. If the power adapter provided with the product can not be used locally, please consult your local dealer.

  • Page 6: Understanding Of A2 Two-Port Gateway

    Because this site has a wealth of features and related detailed configuration options, in your call to enjoy a stress free before you know your A2 two-port gateway. 2.1. The positive of A2 two-port gateway...

  • Page 7: Indicator Signs

    2.2. Indicator signs Name Meaning Description POWER Power LED Always light, has power, you can start using the A2 two-port gateway. FXS1 Phone work Show the status of the phone status lights under the port 1. No phone or hang up: Off; pick up: always.
  • Page 8 A2 two-port gateway with two network interface itself: WAN port and LAN port, you can use the Internet connection into the WAN port or LAN port. Read the manual carefully of “Safety” before inserting the power...

  • Page 9: Getting Started

    Ethernet port in your workspace. Use the Ethernet cable in the package to connect WAN port of A2 two-port gateway to the Ethernet port in your workspace. Since this gateway has router functionality, whether you have a broadband router or not, you can make direct network connect.

  • Page 10: Connect The Power

    3.1.2. Connect the power During this step, make sure your power supply connector and A2 two-port gateway outlet match, while A2 is also in line voltage and current required for a two-port gateway. 1. The transformer connected to the DC port on the back of A2 two-port gateway POWER jack.

  • Page 11: Basic Phone Operation Of A2 Two-Port Gateway

    4. Basic phone operation of A2 two-port gateway Since there are two FXS interfaces on the A2 two-port gateway, and the two interfaces are independent, so the phones under the FXS1 and FXS2 have the same operation. The phones under the two ports can be used as two separate telephones at the same time.

  • Page 12: Web Configuration

    (To use this feature, you must enable the gateway of the Call Waiting feature) 5. Web configuration 5.1. Introduction of configuration 5.1.1. Ways to configure A2 two-port gateway has two different ways to different users. Use web browser（recommendatory way）. Use telnet with CLI command. 5.1.2. Password Configuration There are two levels to access to gateway: root level and general level.

  • Page 13: Configuration Via Web

    5.3. Configuration via WEB 5.3.1. BASIC 5.3.1.1. Status Status Field name Explanation Network Shows the configuration information on WAN and LAN port, including the connect mode of WAN port (Static, DHCP, PPPoE), MAC address, the IP addresses of WAN port and LAN port, ON or OFF of DHCP mode of LAN port.
  • Page 14 Please select the proper network mode according to the network condition. A2 gateway provide three different network settings: Static: If your ISP server provides you the static IP address, please select this mode, and then finish Static Mode setting. If you don’t know about parameters of Static Mode setting, please ask your ISP for them.

  • Page 15: Network

    Enable Register Start to register or not by selecting it or not. Display detailed information that you manual config. Choose DHCP MODE，click【NEXT】can config SIP(default SIP1)simply, also can browse too. Click【BACK】can return to the last page. Like Static IP MODE。 Choose PPPoE MODE， click 【NEXT】 can config the PPPoE account/password and SIP(default SIP1)simply, also can browse too.
  • Page 16 Shows the time of getting MAC address Please select the proper network mode according to the network condition. A2 two-port gateway provide three different network settings: Static: If your ISP server provides you the static IP address, please select this mode, and then finish Static Mode setting. If you don’t know about parameters of Static Mode setting, please ask your ISP for them.

  • Page 17: Lan Config

    If you uses PPPoE mode，you need to make the above setting. PPPoE Server It will be provided by ISP. Username Input your ADSL account. Password Input your ADSL password. Notice: 1）Click “Apply” button after finished your setting, IP gateway will save the setting automatically and new setting will take effect.

  • Page 18: Qos Config

    disabled. 5.3.2.3. Qos Config The gateway support 802.1Q/P protocol and DiffServ configuration. VLAN functionality can use different VLAN IDs by setting signal/voice VLAN and data VLAN. The VLAN application of this device is very flexible. In chart 1, there is two-layer switch without setting VLAN. Any broadcast frame will be transmitted to the other ports except the send port.

  • Page 19: Qos Configuration

    QoS Configuration Field name explanation VLAN Enable Before select it to enable VLAN, you need enable Bridge mode in LAN config. Enable VLAN ID check by selecting it. After enable VLAN Check VLAN ID check, if VLAN ID of a data package is not the Enable same with the gateway or a data package do not have VLAN ID, the data package will be discarded.

  • Page 20: Service Port

    4) Startup VLAN, if set Voice/Data VLAN differentiated as data untagged, then the packet of the signal/voice will use the Voice VLAN ID as the tag, but the data packets will not take the VLAN tag. 5) If Disable the VLAN, regardless to set the Voice/Data VLAN differentiated or not, all packets will not take the VLAN tag;...

  • Page 21: Dhcp Server

    5.3.2.5. DHCP SERVER DHCP SERVER Field name explanation DHCP Leased IP-MAC mapping table. If the LAN port of the gateway Table connects to a device, this table will show the IP and MAC address of this device. Shows the DHCP Lease Table， the unit of Lease time is Minute. Lease Table Name Specify the name of the lease table Start IP...

  • Page 22: Ntp

    between Start IP and End IP by DHCP. Netmask Set the Netmask of the lease table Gateway Set the Gateway of the lease table Lease Time Set the Lease Time of the lease table Set the default DNS server IP of the lease table; Click the Add button to submit and add this lease table Select name of lease table, click the Delete button will delete the selected lease table from DHCP lease table.
  • Page 23 SIP Config Field name explanation Choose line to set info about SIP, there are 3 lines to choose. You can switch by 【Load】 button. Register Status Shows if the gateway has been registered the SIP server or not; or so, show Unapplied; Server Name Set the server name.
  • Page 24 Set proxy server IP address（Usually, Register SIP Server configuration is the same as Proxy SIP Proxy Server Server. But if your VoIP service provider give Address different configurations between Register SIP Server and Proxy SIP Server, you need make different settings.） Proxy Server Port Set your Proxy SIP server port.
  • Page 25 is enable. Enable/Disable keeps NAT of SIP alive. NAT Keep Alive If some server refuse to register with too short interval time, and has no packets sending to device in private network to keep NAT alive, user could set this function ON. And set the interval time less than the NAT server’s.

  • Page 26: Stun Config

    notify from the server. RTP Encode Enable/Disable RTP Encrypt. Enable Session Set Enable/Disable Session Timer, whether support Timer RFC4028.It will refresh the SIP sessions. Answer With Enable/Disable the function when call is incoming, Single Codec phone replies SIP message with just one codec which phone supports.

  • Page 27: Dial Peer Setting

    STUN Field name explanation STUN NAT Transverse Shows STUN NAT Transverse estimation, true means STUN can penetrate NAT, while False means not. STUN Server Addr Set your SIP STUN Server IP address STUN Server Port Set your SIP STUN Server Port Set STUN Effective Time.

  • Page 28: Dial Peer

    01062213123, but you need dial only 162213123 to realize your long distance call after you make this setting. To save the memory and avoid abundant input of user, add the follow functions: 1、x Match any single digit that is dialed. If user makes the above configuration, after user dials 11 digit numbers started with 13, the phone will send out 0 plus the dialed numbers automatically.
  • Page 29 phone number to realize calling to what your prefix number is mapped. The prefix number supports at most 30 digits Set Destination address. This is optional config item. Destination If you want to set peer to peer call, please input destination IP address or domain name.
  • Page 30 phone number are deleted according to delete length. This setting will realize When you dial speed dial function, after “2”, SIP1 you dialing the numeric key server will “2”, the number after all will receive be sent out. 33334444 phone will When you dial automatically...

  • Page 31: Phone

    your dialed phone When you dial number starts with your set “147”, the SIP1 phone number. The phone server will will send out your dialed receive phone number adding “1470011” suffix number. 5.3.4. Phone 5.3.4.1. DSP Config In this page, you can configure voice codec, input/output volume and so on. DSP Configuration Field name explanation...

  • Page 32: Call Service

    Signal Standard Select Signal Standard. Flashhook Min Set the minimum time detection of inserted spring. Time Flashhook Max Set the maximum time inserted spring. Time DTMF Payload DTMF effective load Type Select it or not to enable or disable VAD. If enable VAD, G729 Payload length could not be set over 20ms.
  • Page 33 No Answer Specify No Answer Time Time Do Not Disturb Select NO Disturb, the phone will reject any incoming call, the callers will be reminded by busy, but any outgoing call from the phone will work well. Accept Any If select it, the phone will accept the call even if the called Call number is not belong to the phone.

  • Page 34: Digital Map Configuration

    Notice: Black List and Limit List can record at most10 items respectively. 5.3.4.3. Digital Map Configuration This system supports 4 dial modes: 1). End with “#”: dial your desired number, and then press #. 2). Fixed Length: the phone will intersect the number according to your specified length.

  • Page 35: Maintenance

    in length. n is mandatory and can have a value of 0 to 9 seconds. Tn must be the last 2 characters of a dial plan. If Tn is not specified it is assumed to be T0 by default on all dial plans. Cause extensions 1000-8999 to be dialed immediately Cause 8 digit numbers started with 9 to be dialed immediately Cause 911 to be dialed immediately after it is entered.

  • Page 36: Syslog Config

    System will use MAC as config file name if config file name keep blank. For example, 000102030405.。 Config Encrypt Input the Encrypt Key, if the configuration file is encrypted. Select the Protocol type FTP、TFTP or HTTP. Protocol Type Update Interval Set update interval time, unit is hour.

  • Page 37: Config Setting

    Server Port Set Syslog server port. MGR Log Level Set the level of MGR log. SIP Log Level Set the level of SIP log. Enable Syslog Select it or not to enable or disable syslog. 5.3.5.3. Config Setting Config Setting Field name explanation You can save all changes of configurations.

  • Page 38: Update

    5.3.5.4. Update You can update your configuration with your config file in this web page. Update Field name explanation Click the browse button, find out the config file saved Web Update before or provided by manufacturer, download it to the gateway directly, press “Update”...

  • Page 39: Reboot

    Account Configuration Field name explanation This table shows the current user existed. User Name Set account user name. User Level Set user level, Root user has the right to modify configuration, General can only read. Password Set the password. Confirm Confirm the password.

  • Page 40: Security

    5.3.6. Security 5.3.6.1. MMI Filter MMI Filter User could make some device own IP, which is pre-specified, access to the MMI of the gateway to config and manage the gateway. Field name explanation MMI Filter IP Table list: Add or delete the IP address segments that access to the phone. Set initial IP address in the Start IP column, Set end IP address in the End IP column, and click Add to add this IP segment.

  • Page 41: Firewall

    5.3.6.2. Firewall Firewall Configuration In this web interface, you can set up firewall to prevent unauthorized Internet users from accessing private networks connected to the Internet (input rule), or prevent unauthorized private network devices from accessing the Internet (output rule). Firewall supports two types of rules: input access rule and output access rule.

  • Page 42: Nat Config

    Src Addr Set source address. It can be single IP address, network address, complete address 0.0.0.0, or network address similar to *.*.*.0 source address’ mask. example, Src Mask 255.255.255.255 means just point to one host; 255.255.255.0 means point to a network which network ID is C type.

  • Page 43: Nat Configuration

    NAT Configuration Field name explanation IPSec ALG It is an encryption technology. Select it to enable IPSec ALG, the default is enable FTP is a service of connection layer which can FTP ALG transform intranet IP into extranet IP when intranet IP is sending out packet.

  • Page 44: Vpn Config

    click the Delete button to delete the selected mapping table. 5.3.6.4. VPN Config This web page provides us a safe connect mode by which we can make remote access to enterprise inner network from public network. That is to say, you can set it to connect public networks in different areas into inner network via a special tunnel.

  • Page 45: Logout

    Enable VPN Select it or not to enable or disable VPN； VPN Server Addr Set VPN L2TP Server IP address VPN User Name Set User Name access to VPN L2TP Server VPN Password Set Password access to VPN L2TP Server VPN Server Addr Set VPN PPTP Server IP address VPN User Name...

  • Page 46: Appendix

    6. Appendix 6.1. Specification 6.1.1. Hardware Item A2 GATEWAY Adapter Input: 100-240V (Input/Output) Output: 12V 1A port 10/100Base- T RJ-45 for LAN 10/100Base- T RJ-45 for PC Operation 0～40℃ Temperature Relative Humidity 10～65% main chip Ralink MIPS 24KEC (320MHz) SDRAM Flash 6.1.2.

  • Page 47: Maintenance And Management

    Support Syslog Support Auto Provisioning (upgrade firmware or configuration file) 6.2. Particularly suitable for A2 two-port gateway Service Provider of telecom operators and (ITSP) Internet Telephony Large companies (for international and domestic long distance and / or internal...
  • Page 48 Access modes commonly used example (already installed on your computer dial-up software) Description: Can not 1、Make sure the front of the problem does not exist. access the 2、Make sure that dial-up software is properly installed internet and set. 3、Sure to enter the correct user name and password. 4、If it does not work after the success dial up, make sure the IE browser's proxy server is set correctly.
