FRONT-A UNIT (IC-F2700 Series)
•
FRONT-B UNIT (IC-F2800 Series)
Reset IC
(IC2: S-80942CNMC)
Front CPU
Backlight
dimmer control
(IC3: HD64F3687)
Q3: 2SC4116
Q4: DTC114TU
Q5: DTC114TU
Backlight
Front CPU
(IC3: HD64F3687)
dimmer control
Q3: 2SC4116
Q4: DTC114TU
Q5: DTC114TU
2 - 2
LCD driver
Mic amplifier
(IC7: SED1526F0A)
(IC5: TC75S51F)
ALC amplifier
Mic switch
(IC9: AN6123MS)
(IC8: TC4W53F)
ALC amplifier
(IC9: AN6123MS)
Mic switch
(IC8: TC4W53F)
