Icom IC-F2721 Service Manual page 29

[MAIN UNIT]
REF ORDER
NO. NO.
R321 7030010040 S.RES ERJ2GE-JPW
R322 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R323 7030008410 S.RES ERJ2GEJ 392 X (3.9 kΩ)
R324 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
R325 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
R326 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R327 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R328 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R329 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R332 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R333 7030005160 S.RES ERJ2GEJ 105 X (1 MΩ)
R334 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R335 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R336 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R337 7030004970 S.RES ERJ2GEJ 470 X (47Ω)
R338 7030000460 S.RES MCR10EZHJ 4.7 kΩ
R339 7030000460 S.RES MCR10EZHJ 4.7 kΩ
R340 7030000220 S.RES MCR10EZHJ 47Ω (470)
R341 7030007350 S.RES ERJ2GEJ 393 X (39 kΩ)
R342 7030003320 S.RES ERJ3GEYJ 101 V (100Ω)
R343 7030005100 S.RES ERJ2GEJ 154 X (150 kΩ)
R344 7030005110 S.RES ERJ2GEJ 224 X (220 kΩ)
R345 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R346 7030005110 S.RES ERJ2GEJ 224 X (220 kΩ)
R347 7030006610 S.RES ERJ2GEJ 394 X (390 kΩ)
R348 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R349 7030005110 S.RES ERJ2GEJ 224 X (220 kΩ)
R350 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R351 7030003300 S.RES ERJ3GEYJ 680 V (68Ω)
R352 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R353 7030003300 S.RES ERJ3GEYJ 680 V (68Ω)
R354 7030005110 S.RES ERJ2GEJ 224 X (220 kΩ)
R355 7030005060 S.RES ERJ2GEJ 333 X (33 kΩ)
R359 7030000460 S.RES MCR10EZHJ 4.7 kΩ
R360 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R361 7030005000 S.RES ERJ2GEJ 471 X (470Ω)
R362 7030000620 S.RES MCR10EZHJ 100 kΩ
R363 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R364 7030005210 S.RES ERJ2GEJ 822 X (8.2 kΩ)
R365 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R366 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R367 7030000020 S.RES MCR10EZHJ 1Ω (010)
R368 7030000020 S.RES MCR10EZHJ 1Ω (010)
R370 7410000750 S.ARY EXB-V4V 104JV (100 kΩ)
R371 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R372 7030005651 S.RES ERA3YKD 304V (300 kΩ)
R373 7030005871 S.RES ERA3YKD 104V (100 kΩ)
R374 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R375 7030004980 S.RES ERJ2GEJ 101 X (100Ω)
R376 7030005290 S.RES ERJ2GEJ 682 X (6.8 kΩ)
R377 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R378 7540000290 ABS ERZV10D220
R383 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R384 7030008300 S.RES ERJ2GEJ 184 X (180 kΩ)
R387 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R391 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R392 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R393 7410001140 S.ARY EXB28V104JX
R394 7030005600 S.RES ERJ2GEJ 273 X (27 kΩ)
R395 7030007350 S.RES ERJ2GEJ 393 X (39 kΩ)
R396 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R397 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R398 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R399 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R400 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
R401 7030007340 S.RES ERJ2GEJ 152 X (1.5 kΩ)
R402 7030004980 S.RES ERJ2GEJ 101 X (100Ω)
R405 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R406 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R407 7030000100 S.RES MCR10EZHJ 4.7Ω (4R7)
R408 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R409 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R410 7030000100 S.RES MCR10EZHJ 4.7Ω (4R7)
R411 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R413 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R414 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R415 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R416 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R417 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R420 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R421 7030005160 S.RES ERJ2GEJ 105 X (1 MΩ)
R422 7030005000 S.RES ERJ2GEJ 471 X (470Ω)
R424 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R425 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R426 7030009320 S.RES ERJ2GEJ 4R7 X (4.7Ω)
R427 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R428 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R429 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
DESCRIPTION M.
LOCATION
T 139.3/79.3
B 148/81.2
B 148/79.2
B 150.5/81.2
B 148.9/41.3
B 147.1/34.9
B 148.9/32.9
B 148/74.1
B 148.9/34.9
B 147.1/35.9
B 148.9/23.4
B 147.1/23.4
B 151.6/20.8
B 151.6/23.4
T 147.5/23.2
T 110.2/79.2
T 108.2/79.2
B 16.3/103.8
B 5.3/101.5
B 7.7/102.9
T 53.5/84.1
T 50.3/81.4
T 52.3/81.4
T 48.3/81.4
T 47.3/81.4
T 153.4/91
B 148.9/40.3
B 148/76.8
T 142/72.1
T 142.7/59.6
T 151.4/66.7
B 150.7/40.3
B 148/71.1
T 106.4/79.2
B 131.5/79
B 127.8/79.4
T 16/107.6
T 54.6/79.1
T 53.3/81.4
T 150.3/109
T 142.5/70.4
B 151.5/57.9
B 151.5/47.4
T 95.5/75.3
T 88.8/74.5
B 129.6/67.6
T 126.2/64.5
B 92.6/77.3
B 36.3/50.4
B 36.3/49.4
B 142/39.3
T 54.6/8.9
B 55.8/8.6
T 101.3/69.3
B 96.4/73.7
T 101.9/53.2
T 94.2/50.6
B 68/8.3
B 70.9/9.8
B 68/6.1
B 66/6.1
T 89.9/59.1
B 124.4/61.9
B 59.9/8.3
B 58.9/8.3
T 132.4/14.3
T 129.6/106.9
B 126/106.2
T 110.5/106.8
[F2721D], [F2821D] only T 119.8/19.6
T 105.9/106.7
T 114.8/106.8
B 124.2/106.2
T 127/106.9
B 109.5/106.1
T 130.6/106.9
T 132.6/106.9
T 104.9/106.7
T 102.9/96.9
B 46.1/24.4
B 50/69.6
B 148/75.8
T 25.9/16.1
T 27.4/19.6
B 70.9/10.8
B 79.2/54.5
B 75.2/59.9
[MAIN UNIT]
H/V REF ORDER
NO. NO.
R430 7030009290 S.RES ERJ2GEJ 562 X (5.6 kΩ)
R431 7030005220 S.RES ERJ2GEJ 223 X (22 kΩ)
R432 7030007570 S.RES ERJ2GEJ 122 X (1.2 kΩ)
R433 7030007290 S.RES ERJ2GEJ 222 X (2.2 kΩ)
R434 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R435 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R436 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R437 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R438 7030005240 S.RES ERJ2GEJ 473 X (47 kΩ)
R439 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R440 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R441 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R442 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R443 7030000220 S.RES MCR10EZHJ 47Ω (470)
R446 7030005060 S.RES ERJ2GEJ 333 X (33 kΩ)
R447 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R448 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R449 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R450 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R451 7030006020 S.RES RR0510P-682-D (6.8 kΩ)
R452 7030006020 S.RES RR0510P-682-D (6.8 kΩ)
R453 7030009320 S.RES ERJ2GEJ 4R7 X (4.7Ω)
R454 7030005010 S.RES ERJ2GEJ 681 X (680Ω)
7030009270 S.RES ERJ2GEJ 821 X (820Ω)
R455 7030005120 S.RES ERJ2GEJ 102 X (1 kΩ)
R456 7030005530 S.RES ERJ2GEJ 100 X (10Ω)
R457 7030004980 S.RES ERJ2GEJ 101 X (100Ω)
R458 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R459 7030005030 S.RES ERJ2GEJ 152 X (1.5 kΩ)
R460 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R461 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R462 7030005230 S.RES ERJ2GEJ 334 X (330 kΩ)
R463 7030010040 S.RES ERJ2GE-JPW
R464 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R465 7030008410 S.RES ERJ2GEJ 392 X (3.9 kΩ)
R466 7030005290 S.RES ERJ2GEJ 682 X (6.8 kΩ)
R467 7030010040 S.RES ERJ2GE-JPW
R468 7030010040 S.RES ERJ2GE-JPW
R469 7030004980 S.RES ERJ2GEJ 101 X (100Ω)
R470 7510001730 S.TMR ERTJOEP 473J
R471 7030005220 S.RES ERJ2GEJ 223 X (22 kΩ)
R472 7030005220 S.RES ERJ2GEJ 223 X (22 kΩ)
R473 7030005220 S.RES ERJ2GEJ 223 X (22 kΩ)
R474 7030007340 S.RES ERJ2GEJ 153 X (15 kΩ)
R475 7030007300 S.RES ERJ2GEJ 332 X (3.3 kΩ)
R476 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R477 7030005070 S.RES ERJ2GEJ 683 X (68 kΩ)
R478 7030007570 S.RES ERJ2GEJ 122 X (1.2 kΩ)
R479 7030005050 S.RES ERJ2GEJ 103 X (10 kΩ)
R480 7030005040 S.RES ERJ2GEJ 472 X (4.7 kΩ)
R481 7030005030 S.RES ERJ2GEJ 152 X (1.5 kΩ)
R482 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R483 7510001750 S.TMR NTCG16 4QH 334KT
R484 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R485 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
R486 7030005090 S.RES ERJ2GEJ 104 X (100 kΩ)
C1 4030017420 S.CER ECJ0EC1H470J
C2 4030017420 S.CER ECJ0EC1H470J
C3 4030017460 S.CER ECJ0EB1E102K
C4 4030017330 S.CER ECJ0EF1C104Z
C5 4030017420 S.CER ECJ0EC1H470J
C6 4030017420 S.CER ECJ0EC1H470J
C7 4030017460 S.CER ECJ0EB1E102K
C8 4030018860 S.CER ECJ0EB0J105K
C10 4030017460 S.CER ECJ0EB1E102K
C11 4550003220 S.TAN TEESVA 1E 105M8L
C12 4030016930 S.CER ECJ0EB1A104K
C13 4550003220 S.TAN TEESVA 1E 105M8L
C14 4030017420 S.CER ECJ0EC1H470J
C15 4030017420 S.CER ECJ0EC1H470J
C16 4030017420 S.CER ECJ0EC1H470J
C17 4030017420 S.CER ECJ0EC1H470J
C18 4030017420 S.CER ECJ0EC1H470J
C19 4030016950 S.CER ECJ0EB1A473K
C20 4030017420 S.CER ECJ0EC1H470J
C21 4030016930 S.CER ECJ0EB1A104K
C22 4030017420 S.CER ECJ0EC1H470J
C24 4030017420 S.CER ECJ0EC1H470J
C25 4030017460 S.CER ECJ0EB1E102K
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 7
DESCRIPTION M.
LOCATION
B 77.2/59.9
B 78.2/59.9
B 82.2/51.1
B 83.2/51.1
B 56.9/12.4
B 64.1/8.3
T 102.9/97.9
[F2721D], [F2821D] only T 123.3/7.4
[F2721D], [F2821D] only T 124.2/7.4
T 82.1/86
T 79.2/89.2
[F2721D], [F2821D] only T 122.8/25.5
B 94.3/52.5
B 69.4/97.3
B 142.3/15.9
B 141.3/15.9
[F2721D], [F2821D] only B 90.5/36.9
[F2721D], [F2821D] only B 94.4/30.9
[F2721D], [F2821D] only B 94.4/31.9
T 63.5/47.3
T 65.8/50.3
T 65.8/48.3
[L] B 64.4/46.9
[H] B 64.4/46.9
B 69.8/48.9
T 69.4/49.3
B 77.2/56.5
B 77.2/58.2
T 79.2/55
T 101/65.3
T 98.4/66.3
B 56.4/15.8
T 56.7/12.1
T 117.7/54.6
B 68/34.2
B 67.2/15.3
T 50.9/32.9
T 47.4/22.3
B 116.7/100.8
B 22.3/29.3
B 67.5/39.5
B 69.3/39.5
B 71.6/40.7
B 77/39.5
B 73.6/39.5
B 73.6/40.7
B 76.3/41.7
B 76.3/43.6
B 79.4/39.5
B 82.1/39.4
B 76.3/42.7
B 64.7/22
T 55/10.7
[F2721D], [F2821D] only T 128.8/40.1
[F2721D], [F2821D] only T 127.9/40.1
T 118.7/37.8
T 76.8/8.5
T 76.8/9.5
B 78/63.2
T 75.4/65.8
T 76.4/65.8
T 76.4/68.2
B 84.6/35.4
B 62.6/21
T 50.9/34.9
T 54.9/34.9
T 148.5/9
T 54.9/32.8
T 44.9/33.9
T 43.5/23.1
T 44.9/32.9
T 43.5/24.2
T 46.8/32.9
T 54.4/27.9
T 46.8/33.9
T 52.2/16.2
B 52.1/30.2
B 135.2/8.5
B 142.3/17.7
S.=Surface mount
H/V
