eKey TOCAhome Installation & Operating Manual page 9

Operation
4.3. Programming menu
. (blinking)
Normal operation
00 ... 99
Enter the security code
Enter the left number of
your security code followed
by the OK key. Enter the
r i g h t n u m b e r o f t h e
security code. The initial
standard code is 99. Press
OK. Should you key in the
wrong code 3 times, the
system will be locked for
30 mins.
Eu
enroll user
This menupoint is used to
e n r o l l f i n g e r s i n t h e
system.
1 ... 99
Set user number
Each user has its own user
number. A user number
which is already in use, is
marked with a blinking dot
after the number.
F1 ... F0
Set finger number
Each finger of a user is
saved by using a number.
Chose here the number of
your finger. Start to count
with one at the little left
finger. Count the fingers to
the right little finger until
1 0 . I n s t e a d o f 1 0 t h e
display shows 0.
o1 ... o3
Enter output (channel)
The finger, which has been
e n r o l l e d i n t h e f o r m e r
menu is now assigned to a
c e r t a i n c h a n n e l . F o r
example the forefinger is
used to unlock channel 1.
EF
Enroll Finger
The sensor of the external
u n i t i s a c t i v a t e d . T h e
status display is orange.
Go to the external unit and
d r a g y o u r f i n g e r - a s
described in the operating
manual - over the sensor.
The status display now is
green, which means the
finger has been enrolled
successfully.
Control keys for the
Right, left navigation in
the menu, respectively
changes values in the
du
delete user
This menupoint is used to
delete users. For the user
selected all fingers enrolled
are deleted.
1 ... 99
Set user number
Each user has its own user
number. A user number
which is already in use, is
marked with a blinking dot
after the number.
internal unit
ESC
OK
display
Sc
Security code
This menupoint is used to
s e t t h e s e c u r i t y c o d e
(initial standard setting is
99). It is recommended to
change this standard code
to an individual code.
00 ... 99
Enter new security codes
First enter the left number
o f y o u r s e c u r i t y c o d e ,
followed by the right one.
Without keying in your
new security code, you
c a n n o t a c c e s s t h e
system anymore.
In case you forget your
security code, the only
solution possible is to
reset the system to the
initial standard settings.
Note:
The word „channel" and
„relay" are used
interchangeably.
- 9 -
Terminates the operation
in the menu, respectively
jumps one menupoint
higher
Confirmation,
respectively jumps one
menupoint lower
rr
Reset to initial standard
settings
This menupoint is used to
reset to the initial standard
settings. All data is deleted
w i t h o u t r e c a l l . U s e r r
before you hand over the
system to another owner.
00
Enter the security code
Enter the left number of
your security code followed
by the OK key. Enter the
r i g h t n u m b e r o f t h e
security code. The initial
standard code is 99. Press
O K . I f y o u k e y i n t h e
wrong code 3 times, the
system will be locked for
30 mins.
