- Page 1 General OPERATING INSTRUCTIONS ekey home Fingerscan Access Control System © ekey biometric systems GmbH Operating instructions ekey home Page 1 / 39...
-
Page 2: Table Of Contents
NOTE ON THE OPERATING INSTRUCTIONS ..........................5 ................................5 ARNING SIGNS AND SYMBOLS ................................5 YPOGRAPHICAL CONVENTIONS ......................................5 ALIDITY PRODUCT OVERVIEW - THE EKEY HOME SYSTEM ........................6 GENERAL SAFETY INFORMATION ............................7 ....................................7 NTENDED USE ................................ 7 ECURITY AGAINST MANIPULATION .................................. 8 HAZARDS AT INTENDED USE REQUIREMENTS FOR THE USER .............................. - Page 3 10.1 ......................................37 10.2 ....................................37 LEANING DISPOSAL ....................................38 TECHNICAL DATA .................................. 38 ACCESSORIES ..................................38 DECLARATIONS OF CONFORMITY ............................38 EKEY BRANCH OFFICES ................................38 © ekey biometric systems GmbH Operating instructions ekey home Page 3 / 39...
-
Page 4: Foreword
24 months from the date of purchase. Warranty claims can only be made in the country where the product was sold. ekey records the laims can only be made in the country where the product was sold. ekey records the laims can only be made in the country where the product was sold. -
Page 5: Note On The Operating Instructions
These operating instructions are not subject to updating. You can find the most up-to-date version of these instructions at www.ekey.net . Subject to optical and technical modifications, any liability for misprints excluded. © ekey biometric systems GmbH Operating instructions ekey home Page 5 / 39... -
Page 6: Product Overview - The Ekey Home System
Electric strike / Locking system optional Cable transfer ekey home is a biometric access system which is equipped with a is a biometric access system which is equipped with a finger scanner finger scanner. This scanner reads special features of your finger lines and uses them to recognise people with access rights. -
Page 7: General Safety Information
Electrical Safety All ekey home devices are to be operated by All ekey home devices are to be operated by safety extra-low voltage and powered by adapters from low voltage and powered by adapters from protection class 2 according to VDE 0140 2 according to VDE 0140-1. -
Page 8: Hazards At Intended Use
System changes (fingerprint enrollment, etc.) can only be made via the ekey home control panel situated in a secure area. The access to the menu in the ekey home control panel is secured with a security code. This is an additional obstacle within the system for unauthorized users. - Page 9 General The operator carries out unauthorized changes on the devices … © ekey biometric systems GmbH Operating instructions ekey home Page 9 / 39...
-
Page 10: Ekey Home Finger Scanners
(swi ekey finger scanners are exclusively equipped with line (swipe) sensors. To capture a fingerprint, pe) sensors. To capture a fingerprint, please draw your finger over the sensor. The system . -
Page 11: Opti Cal Signals On The Ekey Home Finger Scanners
CAL SIGNALS ON THE EKEY HOME FINGER SCANNER SCANNERS Your ekey home finger scanner is equipped with LEDs that deliver further information on the operation is equipped with LEDs that deliver further information on the operation is equipped with LEDs that deliver further information on the operational state and individual functions of your system of your system. - Page 12 FS Status LED Function LED Description Normal mode There is no bus connection to the There is no bus connection to the ekey home control panel. Please ORANGE flashing flashing check the connection cables cables. Left: GREEN The system is online – all components all components are communicating correctly.
- Page 13 Status LED Function LED Description Normal mode There is no bus connection to the ekey home control panel. Please check the connection Left: OFF ORANGE flashing cables or apply „Initializing the devices“ as described in chapter 8.2.1.4 or Fehler! Right: OFF slow Verweisquelle konnte nicht gefunden werden..
-
Page 14: Electric Connection
CP IN and ekey home CP WM. The ekey CP DRM is equipped with a LCD display. In addition, the state of the relay outputs is indicated via LEDs. The ekey home control panels are the actuator units within the ekey home system. The finger scanner transmits to the control panel which relay output has to be activated. -
Page 15: Operation
General 8.2 OPERATION 8.2.1 EKEY HOME CP IN AND EKEY HOME CP WM 8.2.1.1 OPERATING THE BUTTONS Four buttons are used for the operation: = OK button: is used to enter the menu and to confirm entries. < and > buttons: are used to change the values on the display or for navigating in the programming menu (see diagram in section 8.2.1.5) -
Page 16: Initializing The Devices
If it was necessary to replace the control panel because it was defective, then fingers had already been recorded in the ekey home finger scanner. In order not to have them deleted, a pre-recorded finger may now be swiped over the sensor, and the initialization process is started without deleting any data. -
Page 17: Overview Of The Programming Menu Of The Control Panel
Define relay switching time See section 8.2.1.11 o1…o3; od Select relay See section Serial # Version 8.2.1.7 Control panel Finger scanner Control panel Finger scanner See section 8.2.1.10 © ekey biometric systems GmbH Operating instructions ekey home Page 17 / 39... -
Page 18: Entering The Security Code
8.2.1.7 ENROLLING A FINGERPRINT IN THE SYSTEM In ekey home a maximum of 99 fingerprints can be enrolled. These 99 fingerprints can be assigned to 99 user IDs. You can for example administrate 11 users, each one enrolling 9 fingerprints or administrate 99 users, each one enrolling only 1 fingerprint or opt for any other mixed setup. - Page 19 „F1.“. You may still record the finger however if you wish to do so. The preceding finger will then be automatically overwritten. 6.) Press the OK button. Consider step 7 only if you have an ekey home control panel with more than 1 relay: ekey home 2 CP IN ekey home 3 CP WM You can now determine which relay is meant to be controlled by the previously selected fingerprint.
- Page 20 Green: The finger has been succesfully recorded (scanned). The enrollment was successful 9.) Enter the user name on the user list, which you maybe have on paper, at the corresponding place. © ekey biometric systems GmbH Operating instructions ekey home Page 20 / 39...
-
Page 21: Deleting A User
7.) Press the OK button 8.) “OK” is displayed for a short time. The device then returns to normal mode 9.) Memorize your security code, or write it down and keep it in a safe place, separately from the ekey home control panel. - Page 22 By pressing the OK button you return to the first two digits of the version number. If you press the ESC button once you have reached the last two digits the display moves up a level in the navigation. © ekey biometric systems GmbH Operating instructions ekey home Page 22 / 39...
-
Page 23: Changing The Relay Switching Times
That relay thereby works as a switch and does not emit an impulse. If there is a power cut or a RESET on the ekey home FS or the ekey home CP due to a trouble signal in this operating mode (relay permanently closed), then the relay always restarts in idle state once the power supply has been reconnected (or after the reset). -
Page 24: Resetting To Factory Settings
The device is now reset to its factory settings (= as when it was delivered). To start operating the device again, proceed from section 8.2.1.4. You must re-initialize the devices. © ekey biometric systems GmbH Operating instructions ekey home Page 24 / 39... -
Page 25: Ekey Home 1 Cp Drm
CONTROLS The ekey home CP DRM has 4 buttons and an LCD display for system operation and programming. It also features a sliding switch to switch on and off the bus termination, as well as 1 LED for relay status and digital input signaling. -
Page 26: Main Menu
When the devices are connected to the power supply, the language selection is displayed on the ekey home 1 CP DRM. Once the boot procedure on the ekey home FS has been completed, the status LED of the finger scanner begins flashing in orange or blue colour. - Page 27 Display appears for about a second 8.) Now the 14-digit serial number and the 4-digit software version number of ekey home 1 CP DRM and ekey home FS (finger scanner) are displayed. The initialization procedure has now been concluded.
-
Page 28: Entering The Security Code
8.2.2.5 ENROLLING A FINGERPRINT IN THE SYSTEM In ekey home a maximum of 99 fingerprints can be enrolled. These 99 fingerprints can be assigned to 99 user IDs. You can for example administrate 11 users, each one enrolling 9 fingerprints or administrate 99 users, each one enrolling only 1 fingerprint or opt for any other mixed setup. - Page 29 THE SENSOR Select finger Press to go one step back. 1.) First, enter the security code as per section 8.2.1.6 2.) Select in the main menu “Enroll user” © ekey biometric systems GmbH Operating instructions ekey home Page 29 / 39...
- Page 30 8.) You will now see a message on the display, asking you to swipe your finger over the sensor or the cancel finger enrollment by pressing the button. © ekey biometric systems GmbH Operating instructions ekey home Page 30 / 39...
- Page 31 9.) Enter the user name on the user list. You have now concluded the finger enrollment. You may now enroll other fingers, or go back to the main menu by pressing © ekey biometric systems GmbH Operating instructions ekey home...
-
Page 32: Deleting A User
It is not possible to delete individual fingers! You can only delete all the user´s enrolled fingers 8.) You can now delete other users or go back to the main menu by pressing © ekey biometric systems GmbH Operating instructions ekey home Page 32 / 39... -
Page 33: Setting A New Security Code
That relay thereby works as a switch and does not emit an impulse. If there is a power cut or a RESET on the ekey home FS or the ekey home CP due to a trouble signal in this operating mode (relay permanently closed), then the relay always restarts in idle state once the power supply has been reconnected (or after the reset). -
Page 34: Resetting To Factory Settings
, the procedure will take a couple of seconds. The system will reset all the settings and delete all the enrolled fingers. At the end of the RESET procedure, you will be asked on the ekey home 1 CP DRM display to select a language, and the ekey home finger scanner lights up orange. -
Page 35: Test Mode
In this mode, you can manually activate the relay output via the menu of the ekey home 1 CP DRM. This way, you can verify in a simple manner whether the locking system was wired properly. - Page 36 3. The finger was incorrectly swiped over the sensor good recognition. 3. See Fehler! Textmarke nicht definiert. ekey home CP IN and ekey home CP WM The status dot on No power supply 1. Check the power supply, where necessary...
- Page 37 Care of the sensor area Sensor areas The sensor area of the finger scanner is the most important element of your ekey home and needs to be taken care of accordingly in order to function durably. The sensor area is self-cleaning and therefore no special maintenance is necessary. If the finger scanner still becomes dirty, wipe the sensor with a damp (not wet), non-scratch or non-abrasive cloth.
- Page 38 The technical specification for each product (ekey home finger scanner and ekey home control panel) can be found in the respective data sheets on the CD-ROM. Accessories ekey supplies a wide range of accessories for its biometric systems. Please contact either your installer or ekey for accessories such as: power supplies...
- Page 39 General ekey biometric systems Deutschland GmbH Liebigstraße 18, D-61130 Nidderau Phone: +49 (6187) 90696-0 Fax: +49 (6187) 90696-20 Technical support: +49 6187 90696 28 E-mail: deutschland@ekey.net Switzerland | Liechtenstein ekey biometric systems Est. Landstrasse 79, FL-9490 Vaduz Phone: +423 235 08 80...
