eKey TOCAhome Installation & Operating Manual page 11

Operation
4.4.2. How to Enrolment of a finger
1. Press the OK key in the inside unit.
2. By using the keys
3. Press
OK
4. By using the keys
5. Press
OK
6. In the display „Eu" (enrol user) is illuminated
7. Press
OK
8. The display shows "1". A flashing dot next to the number signals that this user number is already in
use. Example: "1." Assign the desired user number by using the keys
9. Press
OK
10. The display shows "F1". F1 stands for finger 1. Please start to count your fingers at the left hand with
the little finger. The right little finger has the number 10 (setting "F0" in the display). A flashing dot
next to the number signals that this user number is already in use e.g. for the right forefinger set „F7"
11. Press
OK
12. In the version ekey TOCAhome the display shows "EF". Please continue reading at the next point but
one. In the version TOCAhome 3 you can now determine which relay (channel) should be activated by
the selected finger: "01" is shown. Set the desired channel by using the keys
(Channel 1 is signalised in the display by "01".)
13. The display shows "EF" (Enrol Finger). You now have 60 sec to draw your finger over the sensor.
14. The outside unit has a status display, which signals the state of operation in different colours.
Red The finger could not be scanned successfully
Green Successful scan
Orange Operating state "enrolment". The device is waiting for a finger to be scanned.
Note:
Please try to swipe the finger's biggest area possible over the sensor - starting from the
beginning of the finger joint. This way, you achieve highest possible identification efficiency.
4.5. Deleting a finger
1. Press the key in the inside unit.
OK
2. By using the keys
3. Press OK
4. By using the keys
5. Press
OK
6. In the display „Eu" (enrol user) is illuminated
7. By using the keys
8. Press
OK
9. By using the keys
10. Press
OK
11. is illuminated in the display
OK
12. After pressing OK again the device returns to its normal operation (flashing)
4.6. Reset to standard setting
This process is thought for the case of handing over the device to a new owner or user.
When returning to the initial settings all data from the storage are deleted. The security code is set back
to the factory setting of 99 and both inside and outside unit loses their coupling.
1. Press the OK key in the inside unit.
2. By using the keys
3. Press
OK
4. By using the keys
5. Press
OK
6. In the display „Eu" (enrol user) is illuminated
7. By using the keys
8. Press
OK
9. Enter the security code again (see steps 1-5)
Now the display shows "_._" and in the following for approx. 15 sec "OK" and then ". ." like after delivery.
The inside and outside unit are ready for initial operation.
and enter the left number of the security code (standard setting is 9)
and enter the right number of the security code (standard setting is 9)
and enter the left number of the security code (standard setting is 9)
and enter the right number of the security code (standard setting is 9)
and navigate to "du" (delete user)
and choose the user number you intend to delete from the system.
and enter the left number of the security code (standard setting is 9)
and enter the right number of the security code (standard setting is 9)
and navigate to "rr" (delete user)
- 11 -
and .
and and press .
