- Page 1 Atlona HD/SD-SDI over Optical Fiber Extender User Manual AT-SDI10SR-LC http://www.atlona.com/...
- Page 2 Safety and Notice Atlona AT-SDI10SR-LC HD/SD-SDI over Optical Fiber Extender has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, AT-SDI10SR-LC should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
- Page 3 LC connector, and then perfectly converts it to electrical SDI signal. Both transmitter and receiver provide equalizing and re-clocking at input unit in order to re-construct the signal for consistent quality. The AT-SDI10SR-LC is perfect for today’s broadcast applications, including video production, video editing, studio to studio and studio to CATV head end.
-
Page 4: Package Contents
Package Contents 1x AT-SDI10SR-LC (Transmitter + Receiver) 2x 5V 4A DC power adapter 1x User Manual Technical Specifications 1x User manual Input connector: Transmitter: 1x 75Ω BNC SDI Remote Control (optional) Receiver: 1x Optical LC ... - Page 5 Hardware Installation Transmitter Installation Front View Rear View Signal Detect LC Output: Plug in optical fiber from the left BNC Input: Plug in coaxial cable here Receiver Rear View Front View Signal Detect LC Input: Plug in optical fiber from the LC Output: Plug in coaxial cable here right...
- Page 6 Atlona or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, Atlona, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surges.
