Cleaning The Machine; Replacing The Stitch Plate - Pfaff Espression line Owner's Manual

Cleaning the machine

To keep your sewing machine operating well, clean
Wipe the exterior surface of your machine with a
Wipe the graphic display with a clean, soft and
damp cloth.
Cleaning the bobbin area
Note: Lower the feed dogs and turn off the machine.
plate as shown on the picture, and gently turn
the feed dogs with the brush found with the
accessories.
Cleaning under the bobbin area
Clean the area under the bobbin case after
accumulation of lint in the bobbin case area.
the front part of the bobbin case, by lifting it up.
with the brush.
For 4.2: Use caution when cleaning around
the thread snips knife.
Put the bobbin case and the bobbin case holder
back in place.
Note: Do not blow air into the bobbin case area. The
dust and lint will be blown into your machine.

Replacing the stitch plate

With the feed dogs lowered, place the stitch plate
Press the stitch plate down until it clicks into place.
5:2
B
A
C
