s e C T i o n 5 – a p p e n d i x

Non-Volatile Memory Settings

The iscan Vp20 stores a variety of user settings in non-volatile memory. non-volatile memory
retains its contents when power is lost. There is one group of system settings and one group of user
settings.
System Settings
Table 2. shows system settings.
Table 2. System Settings
Setting
Active Input
Auto StandBy
Video Priority
User Mode
Border Level
Test Pattern Generator
Serial Port Bit Rate
Input/Format Settings
The iscan Vp20 supports an independent set of saved settings based on input and format as shown
in Table 3.
Table 3. Input/Format Settings
Settings
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
27
28
29
30
31
32
33
34
35
37
38
39
40
41
25
Description
one of many Vp20 inputs or auto active input
off or on
priority list of inputs when auto active input is on
normal or advanced
blank to quarter gray
Current selected test pattern
select an available baud rates.
Input
Composite
Composite 2
s-Video
s-Video 2
Component / RGBS 1
Component / RGBS 1
Component / RGBS 1
Component / RGBS 1
Component / RGBS 1
Component / RGBS 1
Component / RGBS 2
Component / RGBS 2
Component / RGBS 2
Component / RGBS 2
Component / RGBS 2
Component / RGBS 2
HDMI 1
HDMI 1
HDMI 1
HDMI 1
HDMI 1
HDMI 1
HDMI 1
HDMI 1
HDMI 1
HDMI 2
HDMI 2
HDMI 2
HDMI 2
HDMI 2
Format
nTsC
PAL/SECAM
nTsC
PAL/SECAM
480i (NTSC)
576i (PAL/SECAM)
480p (NTSC)
576p (PAL/SECAM)
720p (ATSC)
1080i (ATSC)
480i (NTSC)
576i (PAL/SECAM)
480p (NTSC)
576p (PAL/SECAM)
720p (ATSC)
1080i (ATSC)
480i (NTSC)
576i (PAL/SECAM)
480p (NTSC)
576p (PAL/SECAM)
720p (ATSC)
1080i (ATSC)
VGa
sVGa
xGa
480i (NTSC)
576i (PAL/SECAM)
480p (NTSC)
576p (PAL/SECAM)
720p (ATSC)
