Audio Outputs
There are two discrete digital audio outputs, one coaxial and one optical. Both are active at the
same time, with the selected input audio stream. The HDMI output carries both audio and video.

Remote Control Overview

For additional information about the functions of these buttons, turn to the pages given in
parentheses ( ). An asterisk (*) indicates this feature will be implemented in future software.
23
21
20
8
(Up, Left, Enter, Right, Down)
*
Aspect
(HDMI 1, HDMI 2, HDMI 3,
Component 1, Component 2,
S-Video 1, S-Video 2,
Video 1, Video 2, AUTO)
Power/Standby Buttons
The iscan Vp20 remote has a power and a standby button. The power button always turns the
iscan Vp20 on and the standby button always put the unit into standby mode.

Curtain Button

The iScan VP20 remote has a Curtain button which allows you to close a 'curtain' over the image.
This feature is especially useful when an image is paused on a display susceptible to burn-in.
7
7
Curtain
8
Info
STANDBY
7
Standby
Output Setup
OUTPUT
SETUP
Configuration
CONFIG
Picture Control
CONTROL
17
Input Adjust
INPUT
ADJUST
MENU
8
Menu
Navigation Keys
16
Border
BORDER
15
Zoom
ZOOM
HDMI 1
15
HDMI 2
Input Select
HDMI 3
POWER
INFO CURTAIN
ON/OFF
TEST PATTERN
VIEWING INPUT
MODES ASPECT
RATIO
MEMORIES
EXIT
ENTER
CROP
PAN
ASPECT
4:3 16:9
COMP 1 S-VIDEO 1 VIDEO 1
COMP 2 S-VIDEO 2 VIDEO 2
AUTO
INPUT SELECT
7
Power
Test Patterns
21
(Left, On/Off, Right)
*
Viewing Modes
15
Input Aspect
Ratio
8
Exit
*
Crop
16
Pan
16
4:3
16
16:9
