Pro-Form HYBRID TRAINER User Manual page 12

13. The Console (16) requires four AA batteries (not
included); alkaline batteries are recommended.
Do not use old and new batteries together or
alkaline, standard, and rechargeable batter-
ies together. IMPORTANT: If the Console has
been exposed to cold temperatures, allow it
to warm to room temperature before insert-
ing batteries. Otherwise, you may damage
the console displays or other electronic
components.
Remove the battery cover from the back of the
Console (16), and insert batteries into the battery
compartment. Make sure to orient the bat-
teries as shown by the diagram inside the
battery compartment. Then, reattach the bat-
tery cover.
14. Have a second person hold the Console (16)
near the Console Post (73). Connect the wires
on the Console to the Main Wire Harness (45)
and to the Pulse Wires (68).
Insert the excess wire into the Console Post (73)
or into the Console (16).
Tip: Avoid pinching the wires. Attach the
Console (16) to the Console Post (73) with four
M4 x 16mm Screws (47).
13
16
14
16
Avoid pinching
the wires
12
Battery
Cover
45
73
68
47
