ritetemp 6025 Install Manual

Hide thumbs Also See for 6025:

Advertisement

Table of Contents

See also: Operating Manual
Install guide 6025
Caution
• Your thermostat is a precise instrument, handle it with care.
• Turn off electricity to the appliance before installing or
servicing thermostat or any part of the system.
• Do not turn electricity back on until work is completed.
• Do not short (jumper) across electric terminals at control on
furnace or air conditioner to test the system. This will damage
the thermostat and void your warranty.
• All wiring must conform to local codes and ordinances.
• This thermostat is designed for use with 24 volt AC and
millivolt systems. The thermostat should be limited to a
maximum of 1.0 amps; higher amperage may cause damage
to the thermostat.
TAR GET TEM P
HE AT
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6025 and is the answer not in the manual?

Questions and answers

Related Manuals for ritetemp 6025

Summary of Contents for ritetemp 6025

  • Page 1 Install guide 6025 Caution • Your thermostat is a precise instrument, handle it with care. • Turn off electricity to the appliance before installing or servicing thermostat or any part of the system. • Do not turn electricity back on until work is completed.
  • Page 2 Install guide 6025 To avoid electrical shock and to prevent damage to the furnace, air conditioner, Caution and thermostat, disconnect the power supply before beginning work. This can be done at the circuit breaker, or at the appliance. You will need a small Phillips screwdriver and possibly a drill Tools with 3/16-in.

  • Page 3: Remove Old Unit

    • Fill wall opening with non-combustible insulation to prevent drafts. Prepare wires • You will need at least 2.6" of wire for each of your connections to the 6025. 2.6" • If you do not have enough wire, splice additional wire to allow enough slack.

  • Page 4: Before You Connect Wires

    • Wires will dress behind the 6025 and up over the terminal area. • Use the Step-By-Step diagram as your guide. • Do not bunch wires behind 6025. Feed slack back into the wall opening. • Connect labeled wires only to a terminal with corresponding letter.
  • Page 5 Find the set-up diagram for your system • Find the referenece page with your wiring C W RH Go To Page 15 diagram and jumper set-up information. F r o m 2 Wire F u r n a c e Remember, the C wire is optional.

  • Page 6: Install Aaa Batteries

    Mount the 6025 Wall 6025 • Hold the 6025 against the wall, with the wires coming over the top above terminal block. The 6025 will cover the hole in the wall. • Position 6025 for best appearance. Use the optional stand- Wires offs if more space for wires is needed behind the 6025.

  • Page 7: Check Unit

    • Verify that cool air is blowing from the system. Congratulations, you have successfully installed your unit. Please proceed to the OPERATING Guide to initialize the 6025. NOTE: If you have labeled your wires, follow the correct Step-By-Step, and these Check procedures do not operate your system call support at...

  • Page 8: Power Options

    Set the Mode switch to HEAT or COOL. Locate the TIME SET button and press it. The current calibration factor (+/-) of the 6025 will appear in the LCD display as well as the modified temp. Push the UP or DOWN arrows until the desired calibration factor is reached.
  • Page 9 6025. This connects the Heater Power to the thermostat. JUMPERS STEP 2 - Connect the W wire to the W on the 6025. This connects the heater control line to the 6025. STEP 3 - Set Config jumpers per this diagram.
  • Page 10 6025. This connects to the Cooler compressor. STEP 3 - Connect the RH wire to the RH terminal and the RC wire to the RC terminal on the 6025. This connects the Heater and Cooler Power. STEP 4 - Connect the G wire to the G terminal on the Thermostat.
  • Page 11 STEP 1 - Connect O wire to the O terminal or B wire to the B terminal on the 6025. (If you have both O and B -connect O wire to O terminal DO NOT connect B to B terminal - see pg 24 Trane for B wire terminal) STEP 2 - Connect the W2 wire to W2 on the 6025.
  • Page 12 SET JUMPERS Motor driven Valve- Connect the R (or RH) wire to the RH terminal on the 6025. Connect the W wire to the W terminal on the 6025. Connect the remaining wire to the A terminal. Solenoid valve -Connect the R (or RH) wire to the RH terminal on the 6025.

  • Page 13: Wire Reference

    6025 Features This thermostat can be used with all millivolt and 24VAC heating and cooling systems. It cannot be used with line voltage systems. This thermostat is digital and your desired heat or cool temperatures can easily be set on the large screen with the +/- buttons on the front. A minimum 4 minute off time protects heating and cooling systems from damage.

  • Page 14: Jumper Reference

    Solenoid Valves W or W1 Y (the 3rd wire) W 4 5 6 Jumper Reference Configuration jumpers allow your 6025 to be adapted to many different HVAC control applications. RESET UNIT GAS/ELEC HEAT HEAT PUMP AFTER CHANGING JUMPERS GAS or...
  • Page 15 HE AT OF F TA RG ET TE M P CO OL FA N AU TO H E A T Customer Support: 877-505-2353 or Visit our website www.ritetemp-thermostats.com 1611-022...
