- Page 1 Operation 6030 H E A T O F F C O O L FA N A U T O M EN U PR O G ENGLISH...
-
Page 2: Thermostat Mode
2 stage cooling and hybrid systems. Basic Screens The MODE SWITCH of the 6030 must be in the HEAT or the COOL position to access all control functions. The 6030 Thermostat has 3 basic screens. The HOME screen is displayed when unit is operating your system. -
Page 3: Menu Screen
MENU screen Displayed when the MENU button is pressed. Calibration control Set Day Use this to calibrate your LCD Touch this to Touch this area to set display match to another set temperature the day of the week. thermometer. display. Set Time Return Touch this area to set... - Page 4 The Mode Switch must be in Configure HEAT or COOL mode to configure. Press MENU to configure the thermostat (from HOME screen). Set day of the week - Touch the Day of the week area to cycle through the days of the week to select the current day. Set time of day - Touch the Time of Day arrows to move the time selection forward or backward until it displays the...
- Page 5 Program NOTE: 60 Second Rule-During programming, if a button is not pushed in 60 seconds, the unit will return to the home screen. Everything you have changed while programming will automatically be saved. Select HEAT with the HEAT/Cool MODE switch. Press PROGRAM to go to the programming screen.
- Page 6 Manual The 6030 has 3 manual override commands. These are accessed by touching the Current Temp Display at the HOME screen (center of screen). Target Temperature Return HOME HOLD Touch this area to set a comfortable target temp for the system...
- Page 7 At the HOME screen touch the time to toggle from 12 to 24 hr display. Filter The 6030 has a feature that keeps track of actual furnace run time and reminds you to periodically replace your system's air filter. Press MENU and touch FILTER icon.
- Page 8 MENU screen Heat Pump Features If you have configured your 6030 for heat pump control the MENU screen will display an additional icon - the HEAT PUMP ON/OFF icon. When using a heat pump with Auxiliary heat, if the heat pump...
- Page 9 With the switch MODE in HEAT or COOL. Press the MENU button. Press the Temp Up/Temp Down arrows to adjust the temperature reading. CALIBRATE DISPLAY ON will appear. Press HOME to save the new setting. Customer Support: 877-505-2353 or Visit our website www.ritetemp-thermostats.com Made in China 1611-025...
