SECTION 2
•
RF, RF-B, VCO AND FM-TV UNITS
•
LOGIC UNIT
Power amplifier
(IC3: XC62FP3002MR)
CPU system clock
(X1: CR-613)
CPU
(IC1: M38267M8L-256GP)
INSIDE VIEWS
RF UNIT
RF-B UNIT
2nd IF circuit
(FI3: FL-319)
PLL converter circuit
(IC15: TA31056F)
DC-DC converter
IC801: MB3776APFV
Q804: 2SK2493
T1: TO-47
2 - 1
FM-TV UNIT
([OTH-2] only])
VCO UNIT
