LOGIC UNIT
C935
OSD frequency adjustment
CP1
Video synchronous check point
R902
Video synchronous adjustment
R805
DC-DC voltage adjustment
5V
DC-DC voltage check point
FM-TV UNIT
TOP VIEW
R6
R8
R12
R13
Standard signal
generator
CP2
CP2
FM-TV frequency
check point
(Need to solder as
shown right)
BOTTOM VIEW
Solder CP2
5 - 8
Power supply
5 V/1 A
J1, pin 2
L2
FM-TV frequency
adjustment
